CANDriver Class Reference

A general interface for a CAN driver. More...

#include <can/CANDriver.h>

Inheritance diagram for CANDriver:

Public Member Functions
Class const &	getClass () const
Constructor, destructor and reflect
	CANDriver ()
	The default constructor. More...
virtual	~CANDriver ()
	The destructor. More...
template<typename Reflector >
void	reflect (Reflector &r)
	The reflect method. More...
General methods
CANBaudRate	getBaudRate () const
	Return the current baud rate. More...
void	setBaudRate (const CANBaudRate &baudRate)
	Set the baud rate. More...
std::string	getDeviceName () const
	Return the device name for the CAN bus. More...
void	setDeviceName (const std::string &deviceName)
	Set the device name. More...
virtual std::string	getDriverInfo ()
	Get some information about the driver. More...
Methods for open and close the CAN device
virtual void	open ()=0
	Open the CAN driver. More...
virtual void	close ()=0
	Close the CAN driver. More...
virtual CANStatusFlags	getStatus ()=0
	Return the status of the CAN driver. More...
Message exchange methods
virtual void	sendMessage (const CANMessage &msg)=0
	Send a new message over the CAN bus. More...
virtual bool	waitForNextMessage (Duration timeout)=0
	Wait until a next message is available or until the timeout is reached. More...
virtual void	receiveMessage (CANMessage &oMsg, Time &oReceiveTime)=0
	Receive a new message over the CAN bus. More...

Static Public Member Functions
static PseudoClass const &	CLASS ()

Protected Member Functions
virtual Class const &	internalGetClass () const=0

Protected Attributes
std::string	mDeviceName
	The device name. More...
CANBaudRate	mBaudRate
	Used baud rate. More...

Detailed Description

A general interface for a CAN driver.

Constructor & Destructor Documentation

CANDriver()

CANDriver ( )

inline

The default constructor.

~CANDriver()

virtual ~CANDriver ( )

inlinevirtual

The destructor.

Member Function Documentation

reflect()

void reflect ( Reflector &  r )

inline

The reflect method.

getBaudRate()

CANBaudRate getBaudRate ( ) const

inline

Return the current baud rate.

Returns

The baud rate.

setBaudRate()

void setBaudRate ( const CANBaudRate &  baudRate )

inline

Set the baud rate.

Parameters

[in]

baudRate

The baud rate.

getDeviceName()

std::string getDeviceName ( ) const

inline

Return the device name for the CAN bus.

Returns

The device name.

setDeviceName()

void setDeviceName ( const std::string &  deviceName )

inline

Set the device name.

Parameters

[in]

deviceName

The device name.

getDriverInfo()

virtual std::string getDriverInfo ( )

inlinevirtual

Get some information about the driver.

Returns

The driver info string.

Reimplemented in CANDriverPCAN, CANDriverMLCAN, and CANDriverSocketCAN.

open()

virtual void open ( )

pure virtual

Open the CAN driver.

Implemented in CANDriverPCAN, CANDriverMLCAN, and CANDriverSocketCAN.

close()

virtual void close ( )

pure virtual

Close the CAN driver.

Implemented in CANDriverPCAN, CANDriverMLCAN, and CANDriverSocketCAN.

getStatus()

virtual CANStatusFlags getStatus ( )

pure virtual

Return the status of the CAN driver.

Returns

The status of the driver.

Implemented in CANDriverPCAN, CANDriverMLCAN, and CANDriverSocketCAN.

sendMessage()

virtual void sendMessage ( const CANMessage &  msg )

pure virtual

Send a new message over the CAN bus.

Parameters

[in]

msg

The CAN message.

Implemented in CANDriverPCAN, CANDriverMLCAN, and CANDriverSocketCAN.

waitForNextMessage()

virtual bool waitForNextMessage ( Duration  timeout )

pure virtual

Wait until a next message is available or until the timeout is reached.

Parameters

[in]

timeout

How long should we wait for a new message.

Implemented in CANDriverPCAN, CANDriverMLCAN, and CANDriverSocketCAN.

receiveMessage()

virtual void receiveMessage ( CANMessage &  oMsg, Time &  oReceiveTime  )

pure virtual

Receive a new message over the CAN bus.

Parameters

[out]	oMsg	The CAN message.
[out]	oReceiveTime	Time the message was received/send.

Implemented in CANDriverPCAN, CANDriverMLCAN, and CANDriverSocketCAN.

Member Data Documentation

mDeviceName

std::string mDeviceName

protected

The device name.

mBaudRate

CANBaudRate mBaudRate

protected

Used baud rate.

---

The documentation for this class was generated from the following file:

• include/can/CANDriver.h
