Class object which supports some kind of class reflection. More...

#include <factory/Class.h>

Inheritance diagram for Class:

[legend]

Public Member Functions
virtual	~Class ()

virtual std::string const &	getIdentifier () const
	Return identifier for the class. More...

virtual std::string const &	getName () const
	Return name of the class. More...

virtual int	getTypeId () const =0
	Return unique id for the class. More...

virtual Typename	getTypename () const =0
	Returns the platform independent C++ typename of the class. More...

std::map< std::string, std::string > const &	getMetaInfo () const
	Return map with meta information. More...

std::string const &	getMetaInfo (const std::string &meta) const
	Returns meta information for the given meta key. More...

virtual Object *	newInstance () const =0
	Return a new instance of the class associated with the class object. More...

template<class CLASS >
CLASS *	newInstance () const
	Return a new instance of the class associated with the class object. More...

virtual Object *	newInstance (int paramCount,...) const =0
	Return a new instance of the class associated with the class object. More...

virtual Object *	newInstance (std::string const &childIdentifier) const =0
	Return a new instance of the child class with the given identifier. More...

template<class CLASS >
CLASS *	newInstance (std::string const &childIdentifier) const
	Return a new instance of the child class with the given identifier. More...

virtual Object *	newInstance (std::string const &childIdentifier, int paramCount,...) const =0
	Return a new instance of the child class with the given identifier. More...

bool	isClassRegistered (std::string const &classIdentifier) const
	Return true if a class with the desired identifier is registered. More...

void	eraseChild (Class const *const iClass)
	Remove the given child class from the class. More...

void	eraseParent (Class const *const iClass)
	Remove the given class from the list of parents. More...

ClassProxy	getClassByIdentifier (std::string const &classIdentifier) const
	Return the ClassProxy object for the desired Class. More...

std::vector< ClassProxy >	getClassByMeta (std::string const &metaKey, std::string const &metaValue) const
	Return vector of ClassProxy objects matching the meta criterion. More...

template<class T >
std::vector< ClassProxy >	getClassByMeta (T funcPtr) const
	Return vector of Class objects returning true for the given comparison function. More...

std::map< std::string, ClassProxy >	getDerivedClasses () const
	Return registered children for the associated class to the given map. More...

std::map< std::string, ClassProxy >	getDirectParents () const
	Return map with the direct parents of this class. More...

bool	isBaseOf (Class const *const derived) const
	Return true if given class is registered and derived from this class. More...

bool	isBaseOf (ClassProxy derived) const
	Return true if given class is registered and derived from this class. More...

bool	isBaseOf (std::string const &identifier) const
	Return true if given class is registered and derived from this class. More...

bool	isDerivedFrom (Class const *const base) const
	Return true if given class is registered and parent of this class. More...

bool	isDerivedFrom (ClassProxy base) const
	Return true if given class is registered and parent of this class. More...

bool	isDirectlyDerivedFrom (Class const *const base) const
	Return true if the given class is a direct parent. More...

bool	isDirectlyDerivedFrom (ClassProxy base) const
	Return true if the given class is a direct parent. More...

bool	isDeclaredAbstract () const
	Return true if the associated class is declared to be abstract (comparison with isAbstract() allows to detect programming errors.) More...

virtual bool	isAbstract () const =0
	Return true if the associated class is abstract. More...

bool	isLibraryLoaded () const
	Return true if the library which contains the associated class is loaded. More...

template<typename Reflector >
MIRA_SPLIT_REFLECT_MEMBER void	reflectRead (Reflector &r)
	Implementation of class member reflection. More...

template<typename Reflector >
void	reflectWrite (Reflector &r)
	Implementation of class member reflection. More...

bool	operator== (Class const &other) const
	Returns true, if the two classes are identical. More...

bool	operator!= (Class const &other) const
	Returns true, if the two classes are not identical. More...

bool	operator< (Class const &other) const
	Return true, if the comparison of the identifiers returns true. More...

template<typename Reflector >
void	reflectRead (Reflector &r)

Protected Member Functions
virtual Object *	newVAInstance (int paramCount, std::va_list) const =0
	Call the specific constructor depending on the number of parameters passed to the function. More...

	Class (std::string const &identifier, std::string const &name, std::map< std::string, std::string > const &metaInfo, bool libLoaded)
	This function is called: the constructor. More...

	Class (std::string const &identifier, std::string const &name, bool libLoaded)
	This function is called: the constructor. More...

Protected Attributes
std::map< std::string, ClassProxy >	mDerivedChildren
	map of children More...

std::map< std::string, ClassProxy >	mDirectParents
	map of parents More...

std::string	mIdentifier
	class identifier More...

std::string	mName
	class name More...

std::string	mLib
	lib name More...

std::map< std::string, std::string >	mMetaInfo
	meta info of class More...

bool	mLibLoaded
	is associated lib loaded? More...

Friends
class	ClassFactory

template<typename CLASS >
class	TClass

class	ClassProxy

Detailed Description

Class object which supports some kind of class reflection.

Furthermore, the class object acts like a class factory, which is responsible for all registered children of the class.

Constructor & Destructor Documentation

◆ ~Class()

virtual ~Class ( )

virtual

◆ Class() [1/2]

Class	(	std::string const &	identifier,
		std::string const &	name,
		std::map< std::string, std::string > const &	metaInfo,
		bool	libLoaded
	)

protected

This function is called: the constructor.

◆ Class() [2/2]

Class	(	std::string const &	identifier,
		std::string const &	name,
		bool	libLoaded
	)

protected

This function is called: the constructor.

Member Function Documentation

◆ getIdentifier()

virtual std::string const& getIdentifier ( ) const

virtual

Return identifier for the class.

The identifiers probably contains the namespace of the class.

Reimplemented in NullClass, and TemplateClass< CLASS >.

◆ getName()

virtual std::string const& getName ( ) const

virtual

Return name of the class.

The name will not contain any informations about the class namespace (if the macro for automatic extraction of the name has been used). Otherwise the function simply returns the name given in the object macro.

Reimplemented in NullClass, and TemplateClass< CLASS >.

◆ getTypeId()

virtual int getTypeId ( ) const

pure virtual

Return unique id for the class.

Keep in mind that this id is only valid during execution time and only for this process.

Implemented in TClass< CLASS >, TClass< mira::Object >, NullClass, and VacantClass.

◆ getTypename()

virtual Typename getTypename ( ) const

pure virtual

Returns the platform independent C++ typename of the class.

Implemented in TClass< CLASS >, TClass< mira::Object >, NullClass, and VacantClass.

◆ getMetaInfo() [1/2]

std::map<std::string, std::string> const& getMetaInfo ( ) const

Return map with meta information.

meta information is coded as key-value pair.

◆ getMetaInfo() [2/2]

std::string const& getMetaInfo ( const std::string & meta ) const

Returns meta information for the given meta key.

This method is provided for convenience. If the specified meta information is not available an empty string is returned.

◆ newInstance() [1/6]

virtual Object* newInstance ( ) const

pure virtual

Return a new instance of the class associated with the class object.

The derived TClass and VacantClasses will return the derived class type using covariant return types.

Exceptions

XFactoryLogical	If the class is abstract.
XFactoryLogical	If the class has no default constructor

Implemented in TClass< CLASS >, TClass< mira::Object >, VacantClass, and NullClass.

◆ newInstance() [2/6]

CLASS * newInstance ( ) const

inline

Return a new instance of the class associated with the class object.

The class is casted to the desired class type.

Exceptions

XFactoryBadCast	If the cast fails
XFactoryLogical	If the class is abstract.
XFactoryLogical	If the class has no default constructor

◆ newInstance() [3/6]

virtual Object* newInstance	(	int	paramCount,
			...
	)		const

pure virtual

Return a new instance of the class associated with the class object.

A list of parameters for the constructor can be passed. The derived TClass and VacantClasses will NOT return the derived class type since the combination of va_list and covariant return types seems to be unsupported...

Exceptions

XFactoryLogical	If the class is abstract.
XFactoryLogical	If the class has no constructor matching the given parameter list (or if the constructor is not registered)

Implemented in TClass< CLASS >, TClass< mira::Object >, VacantClass, and NullClass.

◆ newInstance() [4/6]

virtual Object* newInstance ( std::string const & childIdentifier ) const

pure virtual

Return a new instance of the child class with the given identifier.

The derived TClass and VacantClasses will return the derived class type using covariant return types.

Exceptions

XFactoryLogical	If the class is abstract.
XFactoryLogical	If the class has no default constructor

Implemented in TClass< CLASS >, TClass< mira::Object >, VacantClass, and NullClass.

◆ newInstance() [5/6]

CLASS * newInstance ( std::string const & childIdentifier ) const

inline

Return a new instance of the child class with the given identifier.

The class is casted to the desired class type.

Exceptions

XFactoryBadCast	If the cast fails
XFactoryLogical	If the class is abstract.
XFactoryLogical	If the class has no default constructor

◆ newInstance() [6/6]

virtual Object* newInstance	(	std::string const &	childIdentifier,
		int	paramCount,
			...
	)		const

pure virtual

Return a new instance of the child class with the given identifier.

A list of parameters for the constructor can be passed. The derived TClass and VacantClasses will NOT return the derived class type since the combination of va_list and covariant return types seems to be unsupported...

Exceptions

XFactoryLogical	If the class is abstract.
XFactoryLogical	If the class has no constructor matching the given parameter list (or if the constructor is not registered)

Implemented in TClass< CLASS >, TClass< mira::Object >, VacantClass, and NullClass.

◆ isClassRegistered()

bool isClassRegistered ( std::string const & classIdentifier ) const

Return true if a class with the desired identifier is registered.

◆ eraseChild()

void eraseChild ( Class const *const iClass )

Remove the given child class from the class.

Calls eraseChild on all parents and removes the given class from its own child list.

◆ eraseParent()

void eraseParent ( Class const *const iClass )

Remove the given class from the list of parents.

Calls eraseParent on all children and removes the given class from its own parent list.

◆ getClassByIdentifier()

ClassProxy getClassByIdentifier ( std::string const & classIdentifier ) const

Return the ClassProxy object for the desired Class.

Exceptions

XFactoryUnknown If the identifier is unknown.

◆ getClassByMeta() [1/2]

std::vector<ClassProxy> getClassByMeta	(	std::string const &	metaKey,
		std::string const &	metaValue
	)		const

Return vector of ClassProxy objects matching the meta criterion.

The returned classes matches the given metakey and metavalue.

◆ getClassByMeta() [2/2]

std::vector< ClassProxy > getClassByMeta ( T funcPtr ) const

inline

Return vector of Class objects returning true for the given comparison function.

The comparison function has to take the meta information std::map<std::string, std::string> const& as argument and should return true if the meta information matches the desired criterion.

◆ getDerivedClasses()

std::map<std::string, ClassProxy> getDerivedClasses ( ) const

Return registered children for the associated class to the given map.

◆ getDirectParents()

std::map<std::string, ClassProxy> getDirectParents ( ) const

Return map with the direct parents of this class.

◆ isBaseOf() [1/3]

bool isBaseOf ( Class const *const derived ) const

Return true if given class is registered and derived from this class.

◆ isBaseOf() [2/3]

bool isBaseOf ( ClassProxy derived ) const

Return true if given class is registered and derived from this class.

◆ isBaseOf() [3/3]

bool isBaseOf ( std::string const & identifier ) const

Return true if given class is registered and derived from this class.

◆ isDerivedFrom() [1/2]

bool isDerivedFrom ( Class const *const base ) const

Return true if given class is registered and parent of this class.

◆ isDerivedFrom() [2/2]

bool isDerivedFrom ( ClassProxy base ) const

Return true if given class is registered and parent of this class.

◆ isDirectlyDerivedFrom() [1/2]

bool isDirectlyDerivedFrom ( Class const *const base ) const

Return true if the given class is a direct parent.

◆ isDirectlyDerivedFrom() [2/2]

bool isDirectlyDerivedFrom ( ClassProxy base ) const

Return true if the given class is a direct parent.

◆ isDeclaredAbstract()

bool isDeclaredAbstract ( ) const

Return true if the associated class is declared to be abstract (comparison with isAbstract() allows to detect programming errors.)

◆ isAbstract()

virtual bool isAbstract ( ) const

pure virtual

Return true if the associated class is abstract.

Implemented in TClass< CLASS >, TClass< mira::Object >, VacantClass, and NullClass.

◆ isLibraryLoaded()

bool isLibraryLoaded ( ) const

Return true if the library which contains the associated class is loaded.

TClass classes will return true and VacantClass classes will return false.

◆ reflectRead() [1/2]

MIRA_SPLIT_REFLECT_MEMBER void reflectRead ( Reflector & r )

Implementation of class member reflection.

Attention: the default implementation will reflect the abstract key in order to read the information from the object. However, the abstract key will be ignored when writing information to the object.

◆ reflectWrite()

void reflectWrite ( Reflector & r )

inline

Implementation of class member reflection.

Attention: the default implementation will reflect the abstract key in order to read the information from the object. However, the abstract key will be ignored when writing information to the object.

◆ operator==()

bool operator== ( Class const & other ) const

inline

Returns true, if the two classes are identical.

◆ operator!=()

bool operator!= ( Class const & other ) const

inline

Returns true, if the two classes are not identical.

◆ operator<()

bool operator< ( Class const & other ) const

inline

Return true, if the comparison of the identifiers returns true.

◆ newVAInstance()

virtual Object* newVAInstance	(	int	paramCount,
		std::va_list
	)		const

protectedpure virtual

Call the specific constructor depending on the number of parameters passed to the function.

Implemented in VacantClass, TClass< CLASS >, TClass< mira::Object >, and NullClass.

◆ reflectRead() [2/2]

void reflectRead ( Reflector & r )

inline

Friends And Related Function Documentation

◆ ClassFactory

friend class ClassFactory

friend

◆ TClass

friend class TClass

friend

◆ ClassProxy

friend class ClassProxy

friend

Member Data Documentation

◆ mDerivedChildren

std::map<std::string, ClassProxy > mDerivedChildren

protected

map of children

◆ mDirectParents

std::map<std::string, ClassProxy> mDirectParents

protected

map of parents

◆ mIdentifier

std::string mIdentifier

protected

class identifier

◆ mName

std::string mName

protected

class name

◆ mLib

std::string mLib

protected

lib name

◆ mMetaInfo

std::map<std::string, std::string> mMetaInfo

protected

meta info of class

◆ mLibLoaded

bool mLibLoaded

protected

is associated lib loaded?

The documentation for this class was generated from the following file:

base/include/factory/Class.h

Public Member Functions

Protected Member Functions

Protected Attributes

Friends

Detailed Description

Constructor & Destructor Documentation

◆ ~Class()

◆ Class() [1/2]

◆ Class() [2/2]

Member Function Documentation

◆ getIdentifier()

◆ getName()

◆ getTypeId()

◆ getTypename()

◆ getMetaInfo() [1/2]

◆ getMetaInfo() [2/2]

◆ newInstance() [1/6]

◆ newInstance() [2/6]

◆ newInstance() [3/6]

◆ newInstance() [4/6]

◆ newInstance() [5/6]

◆ newInstance() [6/6]

◆ isClassRegistered()

◆ eraseChild()

◆ eraseParent()

◆ getClassByIdentifier()

◆ getClassByMeta() [1/2]

◆ getClassByMeta() [2/2]

◆ getDerivedClasses()

◆ getDirectParents()

◆ isBaseOf() [1/3]

◆ isBaseOf() [2/3]

◆ isBaseOf() [3/3]

◆ isDerivedFrom() [1/2]

◆ isDerivedFrom() [2/2]

◆ isDirectlyDerivedFrom() [1/2]

◆ isDirectlyDerivedFrom() [2/2]

◆ isDeclaredAbstract()

◆ isAbstract()

◆ isLibraryLoaded()

◆ reflectRead() [1/2]

◆ reflectWrite()

◆ operator==()

◆ operator!=()

◆ operator<()

◆ newVAInstance()

◆ reflectRead() [2/2]

Friends And Related Function Documentation

◆ ClassFactory

◆ TClass

◆ ClassProxy

Member Data Documentation

◆ mDerivedChildren

◆ mDirectParents

◆ mIdentifier

◆ mName

◆ mLib

◆ mMetaInfo

◆ mLibLoaded
