JSONSerializer Class Reference

Serializer for serializing objects in JSON format. More...

#include <serialization/JSONSerializer.h>

Inheritance diagram for JSONSerializer:
Inheritance graph
[legend]

Public Types

enum  OutputFormat { STANDARD = 0x00, STRING_MAP_AS_OBJECT = 0x01 }
 Flags for JSON output format. More...

typedef boost::mpl::bool_< true > isReadOnly

typedef boost::mpl::bool_< true > isObjectTrackingSupported

typedef Base::VersionType VersionType

typedef Base::ClassVersionMap ClassVersionMap

typedef ReflectorInterface< JSONSerializer >::AcceptDesiredVersion AcceptDesiredVersion

typedef boost::mpl::bool_< true > useHumanReadableIDs
 Specifies, if the Reflector supports human readable IDs. More...

typedef boost::mpl::bool_< false > requireReflectBarriers
 Specifies whether the Reflector uses so-called 'reflect barriers' to allow maintaining separate states for individual blocks of reflected data. More...


Public Member Functions

 MIRA_ENUM_TO_FLAGS_INCLASS (OutputFormat) JSONSerializer(bool readOnly
 Construct a serializer. More...

template<typename T >
VersionType version (VersionType version, const T *caller=NULL)

 MIRA_DEPRECATED ("Please call as version<MyType>(v) or version(v, this)", VersionType version(VersionType version))

template<typename T >
VersionType version (VersionType version, AcceptDesiredVersion, const T *caller=NULL)

template<typename T >
void atomic (T &member)

void atomic (json::Value &member)

template<typename T >
void object (T &member)

template<typename T >
void collection (T &member)

template<typename mapped_type >
void collection (std::map< std::string, mapped_type > &member)

void pointerReference (int referencedObjectID)

void pointerWithClassType (const std::string &type)

void pointerNull ()

template<typename T >
void roproperty (const char *name, const T &member, const char *comment, PropertyHint &&hint=PropertyHint(), ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

template<typename T >
void roproperty (const char *name, const std::string &id, const T &member, const char *comment, PropertyHint &&hint=PropertyHint(), ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

template<typename T >
void roproperty (const char *name, Getter< T > getter, const char *comment, PropertyHint &&hint=PropertyHint(), ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

template<typename Container >
void mapEntry (int id, const typename Container::value_type &p)

void desireClassVersions (const ClassVersionMap &versions)
 implements ReflectorInterface (for documentation see ReflectorInterface) More...

void serialize (const std::string &name, const T &value, const std::string &comment="")
 Serializes the specified object value under the given name. More...

void trackObject (T &member)

void pointer (T *&pointer)

void pointerNormal (T *&pointer, int typeId)

void pointerPolymorphic (T *&pointer, int typeId)

void pointerAbstract (T *&pointer, int typeId)

void pushObjectTrackingStore ()

void popObjectTrackingStore ()

void member (const char *name, T &member, const char *comment, ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void member (const char *name, const std::string &id, T &member, const char *comment, ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void member (const char *name, const T &member, Setter< T > setter, const char *comment, ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void member (const char *name, Getter< T > getter, Setter< T > setter, const char *comment, ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void member (const char *name, T &member, const char *comment, const T &defaultValue, ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void member (const char *name, T &member, const char *comment, const U &defaultValue, ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void member (const char *name, const T &member, Setter< T > setter, const char *comment, const T &defaultValue, ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void member (const char *name, const T &member, Setter< T > setter, const char *comment, const U &defaultValue, ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void member (const char *name, Getter< T > getter, Setter< T > setter, const char *comment, const T &defaultValue, ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void member (const char *name, Getter< T > getter, Setter< T > setter, const char *comment, const U &defaultValue, ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void property (const char *name, T &member, const char *comment, PropertyHint &&hint=PropertyHint(), ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void property (const char *name, const std::string &id, T &member, const char *comment, PropertyHint &&hint=PropertyHint(), ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void property (const char *name, const T &member, Setter< T > setter, const char *comment, PropertyHint &&hint=PropertyHint(), ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void property (const char *name, Getter< T > getter, Setter< T > setter, const char *comment, PropertyHint &&hint=PropertyHint(), ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void property (const char *name, T &member, const char *comment, const T &defaultValue, PropertyHint &&hint=PropertyHint(), ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void property (const char *name, T &member, const char *comment, const U &defaultValue, PropertyHint &&hint=PropertyHint(), ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void property (const char *name, const T &member, Setter< T > setter, const char *comment, const T &defaultValue, PropertyHint &&hint=PropertyHint(), ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void property (const char *name, const T &member, Setter< T > setter, const char *comment, const U &defaultValue, PropertyHint &&hint=PropertyHint(), ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void property (const char *name, Getter< T > getter, Setter< T > setter, const char *comment, const T &defaultValue, PropertyHint &&hint=PropertyHint(), ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void property (const char *name, Getter< T > getter, Setter< T > setter, const char *comment, const U &defaultValue, PropertyHint &&hint=PropertyHint(), ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)

void delegate (T &member, ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)
 Delegates the serialization directly to the specified member, without creating a separate compound for the current object. More...

void delegate (const T &member, Setter< T > setter, ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)
 Delegates the serialization directly to the specified member, without creating a separate compound for the current object. More...

void delegate (Getter< T > getter, Setter< T > setter, ReflectCtrlFlags flags=REFLECT_CTRLFLAG_NONE)
 Delegates the serialization directly to the specified member, without creating a separate compound for the current object. More...

const ReflectMemberMetagetCurrentMemberMeta () const
 Returns the meta-information of the current member that is reflected. More...

const std::string & getCurrentMemberFullID () const
 Returns the full human readable object id / name of the current member being reflected. More...

void invokeMember (T &member, const ReflectMemberMeta &meta)
 Is called to invoke this Reflector on the member with the specified meta information. More...

void invokeMemberOverwrite (T &member, const ReflectMemberMeta &meta)
 The actual invokeMember implementation that is called from invokeMember(). More...

void invokePointerObject (T &member)
 Is called to reflect objects of pointers. More...

void invokeMemberWithoutDefault (T &member, const ReflectMemberMeta &meta)
 Delegates to invokeMember() and rethrows any occurring XMemberNotFound exception as XIO exception. More...

void invokeMemberWithDefault (T &member, const ReflectMemberMeta &meta, const U &defaultValue)
 Delegates to invokeMember() and handles any occurring XMemberNotFound exception by setting the member to the given default value. More...

void invokeMemberWithDefault (T &member, const ReflectMemberMeta &meta, const serialization::IgnoreMissing &defaultValue)
 Delegates to invokeMember() and handles any occurring XMemberNotFound exception by ignoring the exception and hence the missing member, as indicated by IgnoreMissing as default value. More...

VersionType requireVersion (VersionType version, VersionType minVersion, const T *caller=NULL)
 implements ReflectorInterface (for documentation see ReflectorInterface) More...

void requireVersion (VersionType requiredVersion, const T *caller=NULL)
 implements ReflectorInterface (for documentation see ReflectorInterface) More...

VersionType requireVersion (VersionType version, VersionType minVersion, AcceptDesiredVersion, const T *caller=NULL)
 implements ReflectorInterface (for documentation see ReflectorInterface) More...

void requireVersion (VersionType requiredVersion, AcceptDesiredVersion, const T *caller=NULL)
 implements ReflectorInterface (for documentation see ReflectorInterface) More...

 MIRA_DEPRECATED ("Please call as requireVersion<MyType>(v, minV) or requireVersion(v, minV, this)", VersionType requireVersion(VersionType version, VersionType minVersion))

 MIRA_DEPRECATED ("Please call as requireVersion<MyType>(v) or requireVersion(v, this)", void requireVersion(VersionType requiredVersion))

void reflectBase (Base &base)
 implements ReflectorInterface (for documentation see ReflectorInterface) More...

ReflectState preReflect (const char *context="")
 If a reflector requires reflection barriers, preReflect() and postReflect() should be called before/after calling an external method within reflect(), to declare these barriers (such a 'barrier' is just a declaration to the reflector, in fact). More...

void postReflect (const ReflectState &)
 See preReflect for documentation. More...

Special Pointer Handlers For Overwriting
void pointerWithoutClassType ()
 Is called if a pointer points to a non-polymorphic type and hence the object can be stored without specifying a class type. More...

Visiting methods that are called by the RecursiveMemberReflector

while reflecting the members

void enumeration (T &member)
 Is called by the if the member is an enumeration. More...

Optional Class Versioning.

These visiting methods may be supported by different reflectors like the RecursiveMemberReflector and the RPCMethodReflector, etc.

Note
Specifying versions for serialized classes is optional.
requireVersion() and version() currently are supported by serialization reflectors only.
VersionType requireVersion (VersionType version, VersionType minVersion, const T *caller=NULL)
 Same as above, but allows to specify a minimum supported version, and throws XIO if the minimum version requirement is not met. More...

void requireVersion (VersionType version, const T *caller=NULL)
 Specifies the current class version, which is also the minimum (and therefore only) version accepted (therefore, no need to return a version number). More...

VersionType requireVersion (VersionType version, VersionType minVersion, AcceptDesiredVersion, const T *caller=NULL)
 Extension of requireVersion() (see above), that additionally signals the reflector that the caller will properly handle a different version than the one it specifies itself. More...

void requireVersion (VersionType version, AcceptDesiredVersion, const T *caller=NULL)
 Extension of requireVersion() (see above), that additionally signals the reflector that the caller will properly handle a different version than it one it specifies itself. More...

 MIRA_DEPRECATED ("Please call as requireVersion<MyType>(v, minV) or requireVersion(v, minV, this)", VersionType requireVersion(VersionType version, VersionType minVersion))
 Deprecated 'anonymous' (no type) requireVersion(). More...

 MIRA_DEPRECATED ("Please call as requireVersion<MyType>(v) or requireVersion(v, this)", VersionType requireVersion(VersionType version))
 Deprecated 'anonymous' (no type) requireVersion(). More...

VersionType version (VersionType version, const T *caller=NULL)
 Specifies the current class version and returns the version found in the data stream. More...

VersionType version (VersionType version, AcceptDesiredVersion, const T *caller=NULL)
 Extension of version() (see above), that additionally signals the reflector that the caller will properly handle a different version than the one it specifies itself. More...

Methods for reflecting members

These visiting methods are supported by the RecursiveMemberReflector.

void itemName (const std::string &name)
 If the currently reflected object is an item within a collection, this allows to specify an explicit name for that item. More...

Methods for reflecting RPC (remote procedure call) methods
void interface (const char *name)
 Indicates that the class implements the specified RPC interface. More...

void method (const char *name, Method method, const char *comment, const char *paramName, const char *paramDescription, P paramSampleValue,...)
 Specifies that the class that is reflected provides a service through the specified static member function or free function. More...

void method (const char *name, Method method, Class *object, const char *comment, const char *paramName, const char *paramDescription, P paramSampleValue,...)
 Specifies that the class that is reflected provides a service through the specified non-static member function. More...

void method (const char *name, Method method, const char *comment, const char *paramName, const char *paramDescription, P paramSampleValue,...)
 Specifies that the class that is reflected provides a service through the specified function wrapper. More...


Static Public Member Functions

static int forcedSerializeVersion ()
 Returns either the version number from value of environment variable 'MIRA_FORCE_SERIALIZE_VERSION', or -1 (= do not force a version). More...

static void registerClass ()
 Registers a new polymorphic class at the PolymorphPointerReflector. More...

static void unregisterClass ()
 Unregisters the class. More...

static bool isReflectedAsPointer ()
 For internal use only: Returns true, if the type T is ever reflected as pointer within the current translation unit (C file). More...

static bool usesHumanReadableIDs ()
 Returns true, if the concrete derived Reflector supports human readable IDs. More...


Public Attributes

OutputFormat format


Protected Types

typedef std::set< AObject > ObjectSet

typedef std::map< int, std::string > ObjectIDToNameMap

typedef std::pair< ObjectSet, ObjectIDToNameMapTrackingState


Protected Member Functions

VersionType queryDesiredClassVersion (VersionType version, const std::string &type, bool acceptDesiredVersion=false)

VersionType queryDesiredClassVersion (VersionType version, bool acceptDesiredVersion=false)

bool isTrackingEnabled () const
 Returns true, if object tracking is enabled for the type T. More...

const std::string & getHumanReadableFullID (int objectID) const
 Returns the full human readable object id / name for the given internal objectID. More...

void invokeTrackObject (T &member)
 tracks the given object (if pointer tracking is enabled for type T) More...

JSONSerializerThis ()
 "Curiously recurring template pattern" (CRTP). More...

void invoke (T &object)
 Invokes this reflector on the specified object. More...

void invokeOverwrite (T &object)
 The actual invoke implementation, that may also be overwritten in derived classes to add additional functionality. More...


Static Protected Member Functions

static int checkForcedVersion (const std::string &variable)


Protected Attributes

ClassVersionMap mDesiredClassVersions

ObjectSet mObjects

ObjectIDToNameMap mObjectIDToName

std::stack< TrackingStatemTrackingStack


Static Protected Attributes

static constexpr auto MIRA_REFLECTOR_TOPLEVEL_NAME
 Use this when a reflector needs to choose a name for serializing an object. More...


Detailed Description

Serializer for serializing objects in JSON format.

Example usage:

#include <serialization/adapters/std/vector>
// the data to be serialized
std::vector<int> myValue;
...
// create a JSONSerializer that writes into a JSON value
JSONSerializer serializer;
// serialize the data and return the JSON value containing the data
json::Value v = serializer.serialize(myValue);
// write the JSON value to the console
json::write(v, std::cout, true);

For the deserialization of JSON content see JSONDeserializer.

See also
Serialization, JSONDeserializer

Member Typedef Documentation

◆ isReadOnly

typedef boost::mpl::bool_<true> isReadOnly
inherited

◆ isObjectTrackingSupported

typedef boost::mpl::bool_<true> isObjectTrackingSupported
inherited

◆ VersionType

typedef Base::VersionType VersionType
inherited

◆ ClassVersionMap

◆ ObjectSet

typedef std::set<AObject> ObjectSet
protectedinherited

◆ ObjectIDToNameMap

typedef std::map<int, std::string> ObjectIDToNameMap
protectedinherited

◆ TrackingState

typedef std::pair<ObjectSet, ObjectIDToNameMap> TrackingState
protectedinherited

◆ AcceptDesiredVersion

◆ useHumanReadableIDs

typedef boost::mpl::bool_<true> useHumanReadableIDs
inherited

Specifies, if the Reflector supports human readable IDs.

This type must be set to the proper boost::mpl::bool type by the derived Reflector class. (Default is true)

◆ requireReflectBarriers

typedef boost::mpl::bool_<false> requireReflectBarriers
inherited

Specifies whether the Reflector uses so-called 'reflect barriers' to allow maintaining separate states for individual blocks of reflected data.

A reflect barrier is just a virtual separation line declared by a reflected object. It tells the reflector that certain parts of the reflected data should be considered as independent and can have separate states (if the reflector maintains any states for data). As an example, the BinarySerializer reserves space for a version number for each reflected object. If there is more than one individual block, it reserves space for a version for each of the blocks. If the reflector needs reflect barriers, it defines requireReflectBarriers::type to true in its class scope, and defines methods preReflect() and postReflect() that should be called by reflected objects for separation of independent reflection blocks (where the separation is not already implied by visitors like reflector.member()!) (The default is false). Also see ReflectState and MIRA_REFLECT_CALL.

Member Enumeration Documentation

◆ OutputFormat

Flags for JSON output format.

Enumerator
STANDARD

Default format.

STRING_MAP_AS_OBJECT

Serialize associative containers with string keys as JSON object (keys = member names)

Member Function Documentation

◆ MIRA_ENUM_TO_FLAGS_INCLASS()

MIRA_ENUM_TO_FLAGS_INCLASS ( OutputFormat  )

Construct a serializer.

Parameters
readOnlyIf true it also visits ro properties and creates JSON output that should NOT be used to deserialize an object from.

◆ version() [1/4]

VersionType version ( VersionType  version,
const T *  caller = NULL
)
inline

◆ MIRA_DEPRECATED() [1/5]

MIRA_DEPRECATED ( "Please call as version<MyType>(v) or version(v, this)"  ,
VersionType   versionVersionType version
)
inline

◆ version() [2/4]

VersionType version ( VersionType  version,
AcceptDesiredVersion  ,
const T *  caller = NULL
)
inline

◆ atomic() [1/2]

void atomic ( T &  member)
inline

◆ atomic() [2/2]

void atomic ( json::Value member)
inline

◆ object()

void object ( T &  member)
inline

◆ collection() [1/2]

void collection ( T &  member)
inline

◆ collection() [2/2]

void collection ( std::map< std::string, mapped_type > &  member)
inline

◆ pointerReference()

void pointerReference ( int  referencedObjectID)
inline

◆ pointerWithClassType()

void pointerWithClassType ( const std::string &  type)
inline

◆ pointerNull()

void pointerNull ( )
inline

◆ roproperty() [1/3]

void roproperty ( const char *  name,
const T &  member,
const char *  comment,
PropertyHint &&  hint = PropertyHint(),
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inline

◆ roproperty() [2/3]

void roproperty ( const char *  name,
const std::string &  id,
const T &  member,
const char *  comment,
PropertyHint &&  hint = PropertyHint(),
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inline

◆ roproperty() [3/3]

void roproperty ( const char *  name,
Getter< T >  getter,
const char *  comment,
PropertyHint &&  hint = PropertyHint(),
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inline

◆ mapEntry()

void mapEntry ( int  id,
const typename Container::value_type &  p
)
inline

◆ forcedSerializeVersion()

static int forcedSerializeVersion ( )
inlinestaticinherited

Returns either the version number from value of environment variable 'MIRA_FORCE_SERIALIZE_VERSION', or -1 (= do not force a version).

◆ desireClassVersions()

void desireClassVersions ( const ClassVersionMap versions)
inlineinherited

implements ReflectorInterface (for documentation see ReflectorInterface)

◆ queryDesiredClassVersion() [1/2]

VersionType queryDesiredClassVersion ( VersionType  version,
const std::string &  type,
bool  acceptDesiredVersion = false
)
inlineprotectedinherited

◆ queryDesiredClassVersion() [2/2]

VersionType queryDesiredClassVersion ( VersionType  version,
bool  acceptDesiredVersion = false
)
inlineprotectedinherited

◆ serialize()

void serialize ( const std::string &  name,
const T &  value,
const std::string &  comment = ""
)
inlineinherited

Serializes the specified object value under the given name.

If you overwrite this method in a derived class you usually MUST call this method of the base class.

◆ trackObject()

void trackObject ( T &  member)
inlineinherited

◆ pointer()

void pointer ( T *&  pointer)
inlineinherited

◆ pointerNormal()

void pointerNormal ( T *&  pointer,
int  typeId
)
inlineinherited

◆ pointerPolymorphic()

void pointerPolymorphic ( T *&  pointer,
int  typeId
)
inlineinherited

◆ pointerAbstract()

void pointerAbstract ( T *&  pointer,
int  typeId
)
inlineinherited

◆ pointerWithoutClassType()

void pointerWithoutClassType ( )
inlineinherited

Is called if a pointer points to a non-polymorphic type and hence the object can be stored without specifying a class type.

It can be implemented by derived concrete serializers to indicate that no pointer reference and no class type needs to be stored and the full object will follow afterwards. (this is used by the BinarySerializer)

◆ isTrackingEnabled()

bool isTrackingEnabled ( ) const
inlineprotectedinherited

Returns true, if object tracking is enabled for the type T.

◆ pushObjectTrackingStore()

void pushObjectTrackingStore ( )
inlineinherited

◆ popObjectTrackingStore()

void popObjectTrackingStore ( )
inlineinherited

◆ getHumanReadableFullID()

const std::string& getHumanReadableFullID ( int  objectID) const
inlineprotectedinherited

Returns the full human readable object id / name for the given internal objectID.

The human readable id only is available, if the Reflector has set useHumanReadableIDs to true.

◆ member() [1/10]

void member ( const char *  name,
T &  member,
const char *  comment,
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ member() [2/10]

void member ( const char *  name,
const std::string &  id,
T &  member,
const char *  comment,
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ member() [3/10]

void member ( const char *  name,
const T &  member,
Setter< T >  setter,
const char *  comment,
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ member() [4/10]

void member ( const char *  name,
Getter< T >  getter,
Setter< T >  setter,
const char *  comment,
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ member() [5/10]

void member ( const char *  name,
T &  member,
const char *  comment,
const T &  defaultValue,
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ member() [6/10]

void member ( const char *  name,
T &  member,
const char *  comment,
const U &  defaultValue,
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ member() [7/10]

void member ( const char *  name,
const T &  member,
Setter< T >  setter,
const char *  comment,
const T &  defaultValue,
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ member() [8/10]

void member ( const char *  name,
const T &  member,
Setter< T >  setter,
const char *  comment,
const U &  defaultValue,
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ member() [9/10]

void member ( const char *  name,
Getter< T >  getter,
Setter< T >  setter,
const char *  comment,
const T &  defaultValue,
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ member() [10/10]

void member ( const char *  name,
Getter< T >  getter,
Setter< T >  setter,
const char *  comment,
const U &  defaultValue,
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ property() [1/10]

void property ( const char *  name,
T &  member,
const char *  comment,
PropertyHint &&  hint = PropertyHint(),
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ property() [2/10]

void property ( const char *  name,
const std::string &  id,
T &  member,
const char *  comment,
PropertyHint &&  hint = PropertyHint(),
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ property() [3/10]

void property ( const char *  name,
const T &  member,
Setter< T >  setter,
const char *  comment,
PropertyHint &&  hint = PropertyHint(),
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ property() [4/10]

void property ( const char *  name,
Getter< T >  getter,
Setter< T >  setter,
const char *  comment,
PropertyHint &&  hint = PropertyHint(),
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ property() [5/10]

void property ( const char *  name,
T &  member,
const char *  comment,
const T &  defaultValue,
PropertyHint &&  hint = PropertyHint(),
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ property() [6/10]

void property ( const char *  name,
T &  member,
const char *  comment,
const U &  defaultValue,
PropertyHint &&  hint = PropertyHint(),
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ property() [7/10]

void property ( const char *  name,
const T &  member,
Setter< T >  setter,
const char *  comment,
const T &  defaultValue,
PropertyHint &&  hint = PropertyHint(),
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ property() [8/10]

void property ( const char *  name,
const T &  member,
Setter< T >  setter,
const char *  comment,
const U &  defaultValue,
PropertyHint &&  hint = PropertyHint(),
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ property() [9/10]

void property ( const char *  name,
Getter< T >  getter,
Setter< T >  setter,
const char *  comment,
const T &  defaultValue,
PropertyHint &&  hint = PropertyHint(),
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ property() [10/10]

void property ( const char *  name,
Getter< T >  getter,
Setter< T >  setter,
const char *  comment,
const U &  defaultValue,
PropertyHint &&  hint = PropertyHint(),
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

◆ delegate() [1/3]

void delegate ( T &  member,
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

Delegates the serialization directly to the specified member, without creating a separate compound for the current object.

This method usually is used together with IsTransparentSerializable. Note: only one call of delegate is allowed within one reflect method.

◆ delegate() [2/3]

void delegate ( const T &  member,
Setter< T >  setter,
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

Delegates the serialization directly to the specified member, without creating a separate compound for the current object.

This method usually is used together with IsTransparentSerializable. Note: only one call of delegate is allowed within one reflect method.

◆ delegate() [3/3]

void delegate ( Getter< T >  getter,
Setter< T >  setter,
ReflectCtrlFlags  flags = REFLECT_CTRLFLAG_NONE
)
inlineinherited

Delegates the serialization directly to the specified member, without creating a separate compound for the current object.

This method usually is used together with IsTransparentSerializable. Note: only one call of delegate is allowed within one reflect method.

◆ enumeration()

void enumeration ( T &  member)
inlineinherited

Is called by the if the member is an enumeration.

(Type A2)

As for all the other visit-methods the parameter is a reference to the actual visited/reflected member.

The default implementation casts the enum to an uint32 and calls atomic().

◆ registerClass()

static void registerClass ( )
inlinestaticinherited

Registers a new polymorphic class at the PolymorphPointerReflector.

Each RecursiveMemberReflector only is able to process pointers to polymorphic classes that are registered using this method.

The MIRA_CLASS_SERIALIZATION macro provides a simple mechanism to register a class in all known MemberReflectors and calls their registerClass() method. If you implement a new MemberReflector you should modify the MIRA_CLASS_SERIALIZATION macro and add your reflector there.

See also
MIRA_CLASS_SERIALIZATION

◆ unregisterClass()

static void unregisterClass ( )
inlinestaticinherited

Unregisters the class.

The MIRA_CLASS_SERIALIZATION macro provides a simple mechanism to register a class in all known MemberReflectors and calls their registerClass() method. If you implement a new MemberReflector you should modify the MIRA_CLASS_SERIALIZATION macro and add your reflector there.

See also
MIRA_CLASS_SERIALIZATION

◆ getCurrentMemberMeta()

const ReflectMemberMeta& getCurrentMemberMeta ( ) const
inlineinherited

Returns the meta-information of the current member that is reflected.

◆ getCurrentMemberFullID()

const std::string& getCurrentMemberFullID ( ) const
inlineinherited

Returns the full human readable object id / name of the current member being reflected.

This method must not be called if the Reflector has set useHumanReadableIDs to false. If it is called anyway we will assert here.

◆ isReflectedAsPointer()

static bool isReflectedAsPointer ( )
inlinestaticinherited

For internal use only: Returns true, if the type T is ever reflected as pointer within the current translation unit (C file).

◆ invokeTrackObject()

void invokeTrackObject ( T &  member)
inlineprotectedinherited

tracks the given object (if pointer tracking is enabled for type T)

◆ invokeMember()

void invokeMember ( T &  member,
const ReflectMemberMeta meta
)
inlineinherited

Is called to invoke this Reflector on the member with the specified meta information.

This method delegates the call to the most derived invokeMemberOverwrite() method that may be overwritten in subclasses.

Note
Usually, the RecursiveMemberReflector should be invoked using this invokeMember() method instead of the invoke() method of the ReflectorInterface base class. The invoke() method is called internally by the RecursiveMemberReflector.

◆ invokeMemberOverwrite()

void invokeMemberOverwrite ( T &  member,
const ReflectMemberMeta meta
)
inlineinherited

The actual invokeMember implementation that is called from invokeMember().

This method may be overwritten in derived classes to add additional functionality, however, you should always call this implementation of the base class.

◆ invokePointerObject()

void invokePointerObject ( T &  member)
inlineinherited

Is called to reflect objects of pointers.

They will use the same meta as the pointer

◆ invokeMemberWithoutDefault()

void invokeMemberWithoutDefault ( T &  member,
const ReflectMemberMeta meta
)
inlineinherited

Delegates to invokeMember() and rethrows any occurring XMemberNotFound exception as XIO exception.

◆ invokeMemberWithDefault() [1/2]

void invokeMemberWithDefault ( T &  member,
const ReflectMemberMeta meta,
const U &  defaultValue
)
inlineinherited

Delegates to invokeMember() and handles any occurring XMemberNotFound exception by setting the member to the given default value.

◆ invokeMemberWithDefault() [2/2]

void invokeMemberWithDefault ( T &  member,
const ReflectMemberMeta meta,
const serialization::IgnoreMissing defaultValue
)
inlineinherited

Delegates to invokeMember() and handles any occurring XMemberNotFound exception by ignoring the exception and hence the missing member, as indicated by IgnoreMissing as default value.

The value of the member remains unchanged.

◆ requireVersion() [1/8]

VersionType requireVersion ( VersionType  version,
VersionType  minVersion,
const T *  caller = NULL
)
inlineinherited

implements ReflectorInterface (for documentation see ReflectorInterface)

◆ requireVersion() [2/8]

void requireVersion ( VersionType  requiredVersion,
const T *  caller = NULL
)
inlineinherited

implements ReflectorInterface (for documentation see ReflectorInterface)

◆ requireVersion() [3/8]

VersionType requireVersion ( VersionType  version,
VersionType  minVersion,
AcceptDesiredVersion  ,
const T *  caller = NULL
)
inlineinherited

implements ReflectorInterface (for documentation see ReflectorInterface)

◆ requireVersion() [4/8]

void requireVersion ( VersionType  requiredVersion,
AcceptDesiredVersion  ,
const T *  caller = NULL
)
inlineinherited

implements ReflectorInterface (for documentation see ReflectorInterface)

◆ requireVersion() [5/8]

VersionType requireVersion ( VersionType  version,
VersionType  minVersion,
const T *  caller = NULL
)
inlineinherited

Same as above, but allows to specify a minimum supported version, and throws XIO if the minimum version requirement is not met.

Calls version() internally.

Usage:

template<typename Reflector>
void reflect(Reflector& r)
{
VersionType v = r.requireVersion(4, 2, this); // specifies version 4,
// requires version 2 or higher
if(v==3) { // handle reading version 3
...
} else // only versions 2 or 4 remain
...
}
Note
Specifying versions for serialized classes is optional.
requireVersion() and version() currently are supported by serialization reflectors only

◆ requireVersion() [6/8]

void requireVersion ( VersionType  version,
const T *  caller = NULL
)
inlineinherited

Specifies the current class version, which is also the minimum (and therefore only) version accepted (therefore, no need to return a version number).

See above.

◆ requireVersion() [7/8]

VersionType requireVersion ( VersionType  version,
VersionType  minVersion,
AcceptDesiredVersion  ,
const T *  caller = NULL
)
inlineinherited

Extension of requireVersion() (see above), that additionally signals the reflector that the caller will properly handle a different version than the one it specifies itself.

◆ requireVersion() [8/8]

void requireVersion ( VersionType  version,
AcceptDesiredVersion  ,
const T *  caller = NULL
)
inlineinherited

Extension of requireVersion() (see above), that additionally signals the reflector that the caller will properly handle a different version than it one it specifies itself.

◆ MIRA_DEPRECATED() [2/5]

MIRA_DEPRECATED ( "Please call as requireVersion<MyType>(v, minV) or requireVersion(v, minV, this)"  ,
VersionType  requireVersionVersionType version, VersionType minVersion
)
inlineinherited

◆ MIRA_DEPRECATED() [3/5]

MIRA_DEPRECATED ( "Please call as requireVersion<MyType>(v) or requireVersion(v, this)"  ,
void  requireVersionVersionType requiredVersion
)
inlineinherited

◆ MIRA_DEPRECATED() [4/5]

MIRA_DEPRECATED ( "Please call as requireVersion<MyType>(v, minV) or requireVersion(v, minV, this)"  ,
VersionType  requireVersionVersionType version, VersionType minVersion
)
inlineinherited

Deprecated 'anonymous' (no type) requireVersion().

◆ MIRA_DEPRECATED() [5/5]

MIRA_DEPRECATED ( "Please call as requireVersion<MyType>(v) or requireVersion(v, this)"  ,
VersionType  requireVersionVersionType version
)
inlineinherited

Deprecated 'anonymous' (no type) requireVersion().

◆ reflectBase()

void reflectBase ( Base &  base)
inlineinherited

implements ReflectorInterface (for documentation see ReflectorInterface)

◆ This()

JSONSerializer * This ( )
inlineprotectedinherited

"Curiously recurring template pattern" (CRTP).

Safely casts this into Derived. This is safe since when implementing derived class their type is passed as template parameter.

See Wikipedia for more details on CRTP if necessary!

◆ invoke()

void invoke ( T &  object)
inlineprotectedinherited

Invokes this reflector on the specified object.

This is like calling object.reflect(*this). However, this automatically examines if the class T contains a reflect method. In this case it calls the intrusive reflect method, otherwise it uses the non-intrusive reflect method.

◆ invokeOverwrite()

void invokeOverwrite ( T &  object)
inlineprotectedinherited

The actual invoke implementation, that may also be overwritten in derived classes to add additional functionality.

Note
If you overwrite this method you should call the implementation of the base class unless you perform your own invocation process.

◆ version() [3/4]

VersionType version ( VersionType  version,
const T *  caller = NULL
)
inlineinherited

Specifies the current class version and returns the version found in the data stream.

During serialization (read-only reflector), the specified version usually is stored as class version in the data stream. However, the serialized version can be overridden by setting a specific version for a certain class identifier, using desireClassVersions(). In that case, version() may return a different value than specified, and the class' reflect() method must implement reflection according to that version number. During deserialization (write-only reflector), the reflector reads the version found in the data stream and returns it. Providing the type of the caller enables defining separate version numbers for all base classes of an inherited type. Each class in the inheritance hierarchy can store and retrieve a version number independently of all its bases or sub-classes (assuming reflect() calls the reflect() method of the base class using reflectBase()). The type of the caller is also required to look up whether a specific version is desired (see desireClassVersions()). The sole purpose of the 'caller' parameter is to enable automatic deduction of the template parameter T. It can be omitted when T is given explicitly.

Usage:

template<typename Reflector>
void reflect(Reflector& r)
{
VersionType v = r.version(3, this); // specifies current version 3
// in serialization case, normally returns v=3, unless
// configured differently using desireClassVersions()
// in deserialization case, returns the version read from serialized data
// (or throws XIO if that is higher than 3, i.e. incompatible)
r.member("X", x, "");
if (version >= 2)
r.member("X2", x2, "");
if (version == 3)
...
}
Note
Specifying versions for serialized classes is optional.
requireVersion() and version() currently are supported by serialization reflectors only

◆ version() [4/4]

VersionType version ( VersionType  version,
AcceptDesiredVersion  ,
const T *  caller = NULL
)
inlineinherited

Extension of version() (see above), that additionally signals the reflector that the caller will properly handle a different version than the one it specifies itself.

◆ itemName()

void itemName ( const std::string &  name)
inlineinherited

If the currently reflected object is an item within a collection, this allows to specify an explicit name for that item.

This currently is interpreted by the PropertySerializer only.

◆ interface()

void interface ( const char *  name)
inlineinherited

Indicates that the class implements the specified RPC interface.

If you indicate that your class implements the specified interface by calling this method in your reflect method, there is an implicit contract that your class provides all methods that are defined by that interface.

◆ method() [1/3]

void method ( const char *  name,
Method  method,
const char *  comment,
const char *  paramName,
const char *  paramDescription,
paramSampleValue,
  ...
)
inherited

Specifies that the class that is reflected provides a service through the specified static member function or free function.

The method will then be available for RPC calls. For each method its name (used to identify the method in RPC calls) and a comment that describes the method must be specified.

Parameters
nameThe name of the method (used for calling it)
methodThe static member function (or free function) that implements the method
commentA comment that describes the method
paramNameOptional additional argument(s) for the names of the method's parameters
paramDescriptionOptional additional argument(s) for the descriptions of the method's parameters.
paramSampleValueOptional additional argument(s) providing a sample value for each parameter. These are not default values, they are only used for documentation purpose, and should mainly serve to illustrate notation.

The optional parameter documentation arguments must be either a sequence of pairs of const char* values or a sequence of triplets, where each third value is a value of the respective method parameter's type. (name and description must both be provided, for all parameters or for none, and if sample values are to be added, they also need to be added for all parameters).

Examples:

r.method("myMethod1", myStaticMethod1, "static method that does something");
r.method("myMethod2", myStaticMethod2, "static method that does something else",
"x", "1st parameter", "y", "2nd parameter");
r.method("myMethod3", myStaticMethod3, "yet another static method"
"a", "parameter 1", ParamType1(...), "b", "parameter b", ParamType2(...));

◆ method() [2/3]

void method ( const char *  name,
Method  method,
Class object,
const char *  comment,
const char *  paramName,
const char *  paramDescription,
paramSampleValue,
  ...
)
inherited

Specifies that the class that is reflected provides a service through the specified non-static member function.

The method will then be available for RPC calls. For each method its name (used to identify the method in RPC calls) and a comment that describes the method must be specified.

Parameters
nameThe name of the method (used for calling it)
methodThe non-static member function (const or non-const) that implements the method
objectA pointer to the object on which the function is called (usually "this")
commentA comment that describes the method
paramNameOptional additional argument(s) for the names of the method's parameters
paramDescriptionOptional additional argument(s) for the descriptions of the method's parameters.
paramSampleValueOptional additional argument(s) providing a sample value for each parameter.

See above for documentation of optional parameter documentation arguments.

Example:

r.method("myMethod2", &MyClass::myMethod, this, "a non-static method");

◆ method() [3/3]

void method ( const char *  name,
Method  method,
const char *  comment,
const char *  paramName,
const char *  paramDescription,
paramSampleValue,
  ...
)
inherited

Specifies that the class that is reflected provides a service through the specified function wrapper.

The method will then be available for RPC calls. For each method its name (used to identify the method in RPC calls) and a comment that describes the method must be specified.

Parameters
nameThe name of the method (used for calling it)
methodThe function wrapper object that implements the method, e.g. created using boost::bind
commentA comment that describes the method
paramNameOptional additional argument(s) for the names of the method's parameters
paramDescriptionOptional additional argument(s) for the descriptions of the method's parameters.
paramSampleValueOptional additional argument(s) providing a sample value for each parameter.

See above for documentation of optional parameter documentation arguments.

Example:

r.method("myMethod3", boost::bind(&MyClass::myMethod, this, 1.23, 4, _1), "a function wrapper");

◆ usesHumanReadableIDs()

static bool usesHumanReadableIDs ( )
inlinestaticinherited

Returns true, if the concrete derived Reflector supports human readable IDs.

The return value of this method is known at compile time and hence the compiler is able to optimize the code depending on that value.

◆ preReflect()

ReflectState preReflect ( const char *  context = "")
inlineinherited

If a reflector requires reflection barriers, preReflect() and postReflect() should be called before/after calling an external method within reflect(), to declare these barriers (such a 'barrier' is just a declaration to the reflector, in fact).

The base implementation is empty and should not actually be called (if a reflector needs these methods, it must provide own definitions).

Parameters
contextCan be used to provide context, e.g. name of the reflected class or function that is called. How this is used depends on the reflector implementation, e.g. MetaSerializer uses it to generate comments on data elements implicitly defined by preReflect.

The complete process of calling these methods is wrapped by MIRA_REFLECT_CALL. That macro should be used to simplify handling.

See requireReflectBarriers and ReflectState.

◆ postReflect()

void postReflect ( const ReflectState &  )
inlineinherited

See preReflect for documentation.

◆ checkForcedVersion()

static int checkForcedVersion ( const std::string &  variable)
inlinestaticprotectedinherited

Member Data Documentation

◆ format

OutputFormat format
Initial value:
: mReadOnly(readOnly), mOutputFormat(format)
{}
template<typename T>
json::Value serialize(const T& value)
{
mFirstComplex = true;
auto jvalue = json::Value();
mValuePtr = &jvalue;
return jvalue;
}
{
return value;
}

◆ mDesiredClassVersions

ClassVersionMap mDesiredClassVersions
protectedinherited

◆ mObjects

ObjectSet mObjects
protectedinherited

◆ mObjectIDToName

ObjectIDToNameMap mObjectIDToName
protectedinherited

◆ mTrackingStack

std::stack<TrackingState> mTrackingStack
protectedinherited

◆ MIRA_REFLECTOR_TOPLEVEL_NAME

constexpr auto MIRA_REFLECTOR_TOPLEVEL_NAME
staticprotectedinherited

Use this when a reflector needs to choose a name for serializing an object.

Internally this is used to recognize it is not a name defined by the reflected object, but by the reflector.


The documentation for this class was generated from the following file:
