GradientColormap Class Reference

A class for creating continuous color maps based on linear gradients between predefined points. More...

#include <image/Colormap.h>

Inheritance diagram for GradientColormap:

Public Types
typedef iterator	const_iterator

Public Member Functions
	GradientColormap (std::size_t size=256)
void	setColorAt (float position, const Color::RGB &color)
	Sets a color key at the given position with the given color. More...
void	clear ()
	Removes all color keys. More...
virtual Color::RGB	getf (float f) const
	Accesses the continuous colors. More...
void	resize (std::size_t pSize)
	Sets a certain size of this colormap. More...
virtual std::size_t	size () const
	Returns the set size. More...
virtual Color::RGB	get (std::size_t idx) const
	Returns the color at the specified index (must be >= 0 and < size) More...
Color::RGB	operator() (std::size_t idx)
	Returns the color in the colormap at the given index. More...
Color::RGB	operator[] (std::size_t idx)
	Returns the color in the colormap at the given index. More...
iterator	begin ()
	Gives an iterator to the beginning of the colormap. More...
const_iterator	begin () const
	Gives a const iterator to the beginning of the colormap. More...
iterator	end ()
	Gives an iterator to the end of the colormap. More...
const_iterator	end () const
	Gives an const iterator to the end of the colormap. More...
Class const &	getClass () const
	call the virtual internalGetClass(). More...

Static Public Member Functions
static PseudoClass const &	CLASS ()

Protected Member Functions
void	setColorAt (float position, int r, int g, int b)
virtual Class const &	internalGetClass () const =0

Detailed Description

A class for creating continuous color maps based on linear gradients between predefined points.

Each point represents a color at a specific position within the color gradient.

Member Typedef Documentation

const_iterator

typedef iterator const_iterator

inherited

Constructor & Destructor Documentation

GradientColormap()

GradientColormap ( std::size_t  size = 256 )

inline

Member Function Documentation

setColorAt() [1/2]

void setColorAt ( float  position, const Color::RGB &  color  )

inline

Sets a color key at the given position with the given color.

The given position must be in the range 0 to 1.

clear()

void clear ( )

inline

Removes all color keys.

getf()

virtual Color::RGB getf ( float  f ) const

virtualinherited

Accesses the continuous colors.

The specified floating point value must be within the interval [0,1].

Implements ContinuousColormap.

setColorAt() [2/2]

void setColorAt ( float  position, int  r, int  g, int  b  )

inlineprotectedinherited

resize()

void resize ( std::size_t  pSize )

inlineinherited

Sets a certain size of this colormap.

size()

virtual std::size_t size ( ) const

inlinevirtualinherited

Returns the set size.

Implements Colormap.

get()

virtual Color::RGB get ( std::size_t  idx ) const

inlinevirtualinherited

Returns the color at the specified index (must be >= 0 and < size)

Implements Colormap.

operator()()

Color::RGB operator() ( std::size_t  idx )

inlineinherited

Returns the color in the colormap at the given index.

operator[]()

Color::RGB operator[] ( std::size_t  idx )

inlineinherited

Returns the color in the colormap at the given index.

begin() [1/2]

iterator begin ( )

inlineinherited

Gives an iterator to the beginning of the colormap.

begin() [2/2]

const_iterator begin ( ) const

inlineinherited

Gives a const iterator to the beginning of the colormap.

end() [1/2]

iterator end ( )

inlineinherited

Gives an iterator to the end of the colormap.

end() [2/2]

const_iterator end ( ) const

inlineinherited

Gives an const iterator to the end of the colormap.

getClass()

Class const& getClass ( ) const

inlineinherited

call the virtual internalGetClass().

CLASS()

static PseudoClass const& CLASS ( )

inlinestaticinherited

internalGetClass()

virtual Class const& internalGetClass ( ) const

protectedpure virtualinherited

---

The documentation for this class was generated from the following file:

• base/include/image/Colormap.h
