FormulaeColormap Class Referenceabstract

A class for creating formula based color maps. More...

#include <image/Colormap.h>

Inheritance diagram for FormulaeColormap:
Inheritance graph
[legend]

Public Types

typedef iterator const_iterator


Public Member Functions

 FormulaeColormap (std::size_t size=256)

 FormulaeColormap (int rformula, int gformula, int bformula, std::size_t size=256)

void setFormulae (int rformula, int gformula, int bformula)
 Sets the formulae for the color components. More...

virtual Color::RGB getf (float f) const
 Accesses the continuous colors. More...

void resize (std::size_t pSize)
 Sets a certain size of this colormap. More...

virtual std::size_t size () const
 Returns the set size. More...

virtual Color::RGB get (std::size_t idx) const
 Returns the color at the specified index (must be >= 0 and < size) More...

Color::RGB operator() (std::size_t idx)
 Returns the color in the colormap at the given index. More...

Color::RGB operator[] (std::size_t idx)
 Returns the color in the colormap at the given index. More...

iterator begin ()
 Gives an iterator to the beginning of the colormap. More...

const_iterator begin () const
 Gives a const iterator to the beginning of the colormap. More...

iterator end ()
 Gives an iterator to the end of the colormap. More...

const_iterator end () const
 Gives an const iterator to the end of the colormap. More...

Class const & getClass () const
 call the virtual internalGetClass(). More...


Static Public Member Functions

static PseudoClass const & CLASS ()


Protected Member Functions

virtual Class const & internalGetClass () const =0


Detailed Description

A class for creating formula based color maps.

For each RGB color component a formula is given, that specifies, how the component is computed. The advantage of these color maps is, that most of the formulae are at least 2 times differentiable and therefore no changes in the color gradients are visible (which is the case in linear gradient color maps).

The following predefined formulas are available. They correspond to the rgbformulae of gnuplot:

    0: 0               1: 0.5             2: 1
    3: x               4: x^2             5: x^3
    6: x^4             7: sqrt(x)         8: sqrt(sqrt(x))
    9: sin(90x)       10: cos(90x)       11: |x-0.5|
   12: (2x-1)^2       13: sin(180x)      14: |cos(180x)|
   15: sin(360x)      16: cos(360x)      17: |sin(360x)|
   18: |cos(360x)|    19: |sin(720x)|    20: |cos(720x)|
   21: 3x             22: 3x-1           23: 3x-2
   24: |3x-1|         25: |3x-2|         26: (3x-1)/2
   27: (3x-2)/2       28: |(3x-1)/2|     29: |(3x-2)/2|
   30: x/0.32-0.78125 31: 2*x-0.84       32: 4x;1;-2x+1.84;x/0.08-11.5
   33: |2*x - 0.5|    34: 2*x            35: 2*x - 0.5
   36: 2*x - 1

Member Typedef Documentation

◆ const_iterator

typedef iterator const_iterator
inherited

Constructor & Destructor Documentation

◆ FormulaeColormap() [1/2]

FormulaeColormap ( std::size_t  size = 256)
inline

◆ FormulaeColormap() [2/2]

FormulaeColormap ( int  rformula,
int  gformula,
int  bformula,
std::size_t  size = 256
)
inline

Member Function Documentation

◆ setFormulae()

void setFormulae ( int  rformula,
int  gformula,
int  bformula
)
inline

Sets the formulae for the color components.

◆ getf()

virtual Color::RGB getf ( float  f) const
virtualinherited

Accesses the continuous colors.

The specified floating point value must be within the interval [0,1].

Implements ContinuousColormap.

◆ resize()

void resize ( std::size_t  pSize)
inlineinherited

Sets a certain size of this colormap.

◆ size()

virtual std::size_t size ( ) const
inlinevirtualinherited

Returns the set size.

Implements Colormap.

◆ get()

virtual Color::RGB get ( std::size_t  idx) const
inlinevirtualinherited

Returns the color at the specified index (must be >= 0 and < size)

Implements Colormap.

◆ operator()()

Color::RGB operator() ( std::size_t  idx)
inlineinherited

Returns the color in the colormap at the given index.

◆ operator[]()

Color::RGB operator[] ( std::size_t  idx)
inlineinherited

Returns the color in the colormap at the given index.

◆ begin() [1/2]

iterator begin ( )
inlineinherited

Gives an iterator to the beginning of the colormap.

◆ begin() [2/2]

const_iterator begin ( ) const
inlineinherited

Gives a const iterator to the beginning of the colormap.

◆ end() [1/2]

iterator end ( )
inlineinherited

Gives an iterator to the end of the colormap.

◆ end() [2/2]

const_iterator end ( ) const
inlineinherited

Gives an const iterator to the end of the colormap.

◆ getClass()

Class const& getClass ( ) const
inlineinherited

call the virtual internalGetClass().

◆ CLASS()

static PseudoClass const& CLASS ( )
inlinestaticinherited

◆ internalGetClass()

virtual Class const& internalGetClass ( ) const
protectedpure virtualinherited

The documentation for this class was generated from the following file:
