Angle.h File Reference

Implementations of angles (values in periodic interval of width 2*pi) with arbitrary base type. More...

#include <type_traits>
#include <error/Exceptions.h>
#include <platform/Platform.h>
#include <math/Math.h>
#include <serialization/Accessor.h>

Include dependency graph for Angle.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
class	AngleBase< T, UnitTag, Derived >
	Base class template for derived Angle implementations. More...
class	DegreeBase< T, Derived >
	Base class for angle classes that represent angles using degrees. More...
class	RadianBase< T, Derived >
	Base class for angle classes that represent angles using radians. More...
class	Degree< T >
	Unsigned angle that is represented using degrees. More...
class	SignedDegree< T >
	Signed angle that is represented using degrees. More...
class	IsTransparentSerializable< SignedDegree< T >, SerializerTag >
class	Degree< T >
	Unsigned angle that is represented using degrees. More...
class	IsTransparentSerializable< Degree< T >, SerializerTag >
class	Radian< T >
	Unsigned angle that is represented using radians. More...
class	SignedRadian< T >
	Signed angle that is represented using radians. More...
class	IsTransparentSerializable< SignedRadian< T >, SerializerTag >
class	Radian< T >
	Unsigned angle that is represented using radians. More...
class	IsTransparentSerializable< Radian< T >, SerializerTag >
class	Angle< T >
	Unsigned angle that is represented using radians. More...
class	SignedAngle< T >
	Signed angle that is represented using radians. More...
class	IsTransparentSerializable< SignedAngle< T >, SerializerTag >
class	Angle< T >
	Unsigned angle that is represented using radians. More...
class	IsTransparentSerializable< Angle< T >, SerializerTag >
struct	Deg2RadNonNegativeType
	A tag type used as parameter type in deg2radSetter, signalling that negative values are not permitted. More...

Namespaces
	mira
	specialize cv::DataType for our ImgPixel and inherit from cv::DataType<Vec>

Macros
#define	_MIRA_ANGLE_H_
#define	MIRA_ANGLE_CONSTRUCTORS_AND_ASSIGNOPS(Type)

Typedefs
typedef SignedDegree< int >	SignedDegreei
	Integer precision signed angle. More...
typedef SignedDegree< float >	SignedDegreef
	Float precision signed angle. More...
typedef SignedDegree< double >	SignedDegreed
	Double precision signed angle. More...
typedef Degree< int >	Degreei
	Integer precision angle. More...
typedef Degree< float >	Degreef
	Float precision angle. More...
typedef Degree< double >	Degreed
	Double precision angle. More...
typedef SignedRadian< float >	SignedRadianf
	Float precision signed angle. More...
typedef SignedRadian< double >	SignedRadiand
	Double precision signed angle. More...
typedef Radian< float >	Radianf
	Float precision angle. More...
typedef Radian< double >	Radiand
	Double precision angle. More...
typedef SignedAngle< float >	SignedAnglef
	Float precision signed angle. More...
typedef SignedAngle< double >	SignedAngled
	Double precision signed angle. More...
typedef Angle< float >	Anglef
	Float precision angle. More...
typedef Angle< double >	Angled
	Double precision angle. More...

Functions
template<typename T >
INTERNAL std::enable_if < std::is_floating_point< T > ::value, T >::type	deg2rad (T value)
	Convert degree to radian, for floating point arguments (return type = argument type) More...
template<typename T >
std::enable_if < std::is_integral< T >::value, double >::type	deg2rad (T value)
	Convert degree to radian, for integral arguments (return type = double) More...
template<typename T >
std::enable_if <!std::is_arithmetic< T > ::value >::type	deg2rad (T value)
template<typename T >
std::enable_if < std::is_floating_point< T > ::value, T >::type	rad2deg (T value)
	Convert radian to degree, for floating point arguments (return type = argument type) More...
template<typename T >
std::enable_if < std::is_integral< T >::value, double >::type	rad2deg (T value)
	Convert radian to degree, for integral arguments (return type = double) More...
template<typename T >
std::enable_if <!std::is_arithmetic< T > ::value >::type	rad2deg (T value)
template<typename T >
T	smallestAngleDifference (const T &a, const T &b)
	Returns the signed difference angle between the specified angles (in radian) that has the smallest absolute value. More...
template<typename T >
bool	inAngleInterval (T value, T min, T max)
template<typename T >
bool	isInAngleInterval (T value, T min, T max)
	Returns true, if the given angle (in radian) is in the given interval [min,max]. More...
template<typename T >
Getter< T >	rad2degGetter (const T &cref)
	Create a getter for serializing radians as degrees. More...
template<typename T >
Setter< T >	deg2radSetter (T &ref)
	Create setter for deserializing radians from degrees. See rad2degGetter. More...
template<typename T >
Setter< T >	deg2radSetter (T &ref, Deg2RadNonNegativeType)
	Create a setter for deserializing radians from degrees. More...
template<typename T >
Accessor< Getter< T >, Setter < T > >	radAsDegAccessor (T &ref)
	Create an accessor consisting of getter + setter for serializing radians as degrees. More...
template<typename T >
Accessor< Getter< T >, Setter < T > >	radAsDegAccessor (T &ref, Deg2RadNonNegativeType)
	Create a complete accessor consisting of getter + setter for serializing radians as degrees. More...
template<typename T , typename UnitTag , typename Derived >
Derived	abs (const mira::AngleBase< T, UnitTag, Derived > &other)

Variables
constexpr Deg2RadNonNegativeType	Deg2RadNonNegative
	Use this constant as second parameter when calling deg2radSetter, in order to prohibit negative values. More...

Detailed Description

Implementations of angles (values in periodic interval of width 2*pi) with arbitrary base type.

Author

Erik Einhorn

Date

2010/08/02

Macro Definition Documentation

#define _MIRA_ANGLE_H_

#define MIRA_ANGLE_CONSTRUCTORS_AND_ASSIGNOPS

(

Type

)

Value:

protected:                                                                     \
    Type(const T& value, int) : Base(value,1) {}                               \
public:                                                                        \
    Type() {}                                                                  \
    explicit Type(T value) : Base(value) {}                                    \
    template <typename OtherT, typename OtherUnitTag, typename OtherDerived>   \
    Type(const AngleBase<OtherT,OtherUnitTag,OtherDerived>& other) : Base(other) {} \
    template <typename OtherUnitTag, typename OtherDerived>                    \
    Type& operator=(const AngleBase<T,OtherUnitTag,OtherDerived>& other) {     \
        Base::operator=(other);                                                \
        return *this; }                                                        \
    Type& operator=(const T& other) {                                          \
        Base::operator=(other);                                                \
        return *this; }
