AbstractChannelSubscriber Class Reference

#include <fw/AbstractChannelSubscriber.h>

Inheritance diagram for AbstractChannelSubscriber:

Public Member Functions
	AbstractChannelSubscriber (DispatcherThread *dispatcher, DiagnosticsModulePtr diagnosticsModule)
	Constructs a subscriber and enables it by default. More...
virtual	~AbstractChannelSubscriber ()
virtual void	signal ()
	Is called from the subscribed Channel whenever data changes. More...
virtual void	unsignal ()
void	enable (bool enabled)
	Enable or disable the subscriber. More...
bool	isEnabled () const
	Returns if this subscriber is enabled. More...
virtual AbstractChannel *	getChannel ()=0
	Returns the channel we are subscribed on, or NULL otherwise. More...
virtual void	detachChannel ()=0
	Is called by AbstractChannel::removeSubscriber() when the subscriber detaches from the channel it is subscribed on. More...
DispatcherThread *	getDispatcher ()
void	setDiagnosticsModule (DiagnosticsModulePtr module)
DiagnosticsModulePtr	getDiagnosticsModule ()

Protected Member Functions
virtual void	run (DispatcherThread *dispatcher)=0
	Called from dispatcher thread this runnable is attached to, whenever the runnable should be executed. More...

Protected Attributes
DispatcherThread *	mDispatcher
bool	mEnabled
	Is the subscriber enabled. More...
DiagnosticsModulePtr	mDiagnosticsModule

Detailed Description

Abstract base class for all typed ChannelSubscriber. This base class is used by SubscriberHandler to store different ChannelSubscriber within the same queue.

Constructor & Destructor Documentation

AbstractChannelSubscriber()

AbstractChannelSubscriber ( DispatcherThread *  dispatcher, DiagnosticsModulePtr  diagnosticsModule  )

inline

Constructs a subscriber and enables it by default.

~AbstractChannelSubscriber()

virtual ~AbstractChannelSubscriber ( )

inlinevirtual

Member Function Documentation

signal()

virtual void signal ( )

virtual

Is called from the subscribed Channel whenever data changes.

unsignal()

virtual void unsignal ( )

virtual

enable()

void enable ( bool  enabled )

inline

Enable or disable the subscriber.

Disabled subscribers may not get informed upon changes in their subscribed channel.

isEnabled()

bool isEnabled ( ) const

inline

Returns if this subscriber is enabled.

getChannel()

virtual AbstractChannel* getChannel ( )

pure virtual

Returns the channel we are subscribed on, or NULL otherwise.

Implemented in ChannelSubscriber< T, ChannelRead >.

detachChannel()

virtual void detachChannel ( )

pure virtual

Is called by AbstractChannel::removeSubscriber() when the subscriber detaches from the channel it is subscribed on.

Implemented in ChannelSubscriber< T, ChannelRead >.

getDispatcher()

DispatcherThread* getDispatcher ( )

inline

setDiagnosticsModule()

void setDiagnosticsModule ( DiagnosticsModulePtr  module )

inlineinherited

getDiagnosticsModule()

DiagnosticsModulePtr getDiagnosticsModule ( )

inlineinherited

run()

virtual void run ( DispatcherThread *  dispatcher )

protectedpure virtualinherited

Called from dispatcher thread this runnable is attached to, whenever the runnable should be executed.

Implemented in DispatcherThread::Timer, FunctionRunnable< F >, ChannelSubscriber< T, ChannelRead >, ServiceInterfaceHandler, and RPCHandler::InvokerRunnable.

Member Data Documentation

mDispatcher

DispatcherThread* mDispatcher

protected

mEnabled

bool mEnabled

protected

Is the subscriber enabled.

mDiagnosticsModule

DiagnosticsModulePtr mDiagnosticsModule

protectedinherited

---

The documentation for this class was generated from the following file:

• framework/include/fw/AbstractChannelSubscriber.h
