Img.h File Reference

Header file containing Img classes that wrap cv::Mat. More...

#include <opencv2/core/core.hpp>
#include <opencv2/imgproc/imgproc.hpp>
#include <platform/Types.h>
#include <geometry/Polygon.h>
#include <geometry/Size.h>
#include <serialization/BinarySerializer.h>
#include <serialization/NoGenericReflect.h>
#include <serialization/IsNotMetaSerializable.h>
#include <image/ImgPixel.h>
#include <image/ImgIterator.h>

Include dependency graph for Img.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
class	ImgBase< TImg >
	ImgBase class. More...
struct	ImgBase< TImg >::ImgFormat
	Image storage format description (used e.g. More...
class	ImgTypedBase< TImg, TPixel >
	Base class for typed images. More...
class	Img< T, TChannels >
	class for typed images. More...
class	Img< T, 1 >
	specialized typed image with 1 channel This template class provides convenient way to create an image with known type and only 1 channel by using Img<Type> More...
class	Img< void, 1 >
	untyped image class This class provides a fully dynamic image, where type and channels are not known at compile time. More...
class	IsNotMetaSerializable< Img< TPixel, TChannels > >
	Mark image classes as not meta-serializable. More...

Namespaces
	mira
	specialize cv::DataType for our ImgPixel and inherit from cv::DataType<Vec>

Macros
#define	MIRA_USE_IPL_IMAGE   0
	IplImage was removed in OpenCV-4.x. More...

Typedefs
typedef Img< uint8, 1 >	Img8U1
	Image: unsigned 8-bit integers, 1 channel. More...
typedef Img< uint8, 2 >	Img8U2
	Image: unsigned 8-bit integers, 2 channels. More...
typedef Img< uint8, 3 >	Img8U3
	Image: unsigned 8-bit integers, 3 channel. More...
typedef Img< uint8, 4 >	Img8U4
	Image: unsigned 8-bit integers, 4 channel. More...
typedef Img< uint16, 1 >	Img16U1
	Image: unsigned 16-bit integers, 1 channel. More...
typedef Img< uint16, 2 >	Img16U2
	Image: unsigned 16-bit integers, 2 channel. More...
typedef Img< uint16, 3 >	Img16U3
	Image: unsigned 16-bit integers, 3 channel. More...
typedef Img< uint16, 4 >	Img16U4
	Image: unsigned 16-bit integers, 4 channel. More...
typedef Img< int16, 1 >	Img16S1
	Image: 16-bit integers, 1 channel. More...
typedef Img< int16, 2 >	Img16S2
	Image: 16-bit integers, 2 channel. More...
typedef Img< int16, 3 >	Img16S3
	Image: 16-bit integers, 3 channel. More...
typedef Img< int16, 4 >	Img16S4
	Image: 16-bit integers, 4 channel. More...
typedef Img< float, 1 >	Img32F1
	Image: floating-point numbers, 1 channel. More...
typedef Img< float, 2 >	Img32F2
	Image: floating-point numbers, 2 channel. More...
typedef Img< float, 3 >	Img32F3
	Image: floating-point numbers, 3 channel. More...
typedef Img< float, 4 >	Img32F4
	Image: floating-point numbers, 4 channel. More...
typedef Img< double, 1 >	Img64F1
	Image: double precision floating-point numbers, 1 channel. More...
typedef Img< double, 2 >	Img64F2
	Image: double precision floating-point numbers, 2 channel. More...
typedef Img< double, 3 >	Img64F3
	Image: double precision floating-point numbers, 3 channel. More...
typedef Img< double, 4 >	Img64F4
	Image: double precision floating-point numbers, 4 channel. More...

Functions
template<typename TPixel , int TChannels>
Img< TPixel, TChannels >	img_cast (Img<> &other)
	Casts an untyped Img<> into a typed image with the specified pixel type and channel count. More...

Detailed Description

Header file containing Img classes that wrap cv::Mat.

Author

Michael Volkhardt

Date

2010/10/18

Macro Definition Documentation

MIRA_USE_IPL_IMAGE

#define MIRA_USE_IPL_IMAGE   0

IplImage was removed in OpenCV-4.x.

By default, we don't use the old OpenCV IplImage. If somebody really needs this (only OpenCV < 4.x) MIRA must be compiled with -DMIRA_USE_IPL_IMAGE=1
