VisualizationViewTransformable Class Referenceabstract

Abstract base class for 2D, 3D, text and plot visualization views (namely Visualization2DView and Visualization3DView...) that support a target frame. More...

#include <views/VisualizationView.h>

Inheritance diagram for VisualizationViewTransformable:
Inheritance graph
[legend]

Signals

void editorClosed (EditorPart *editor)

void editorDestroyed (EditorPart *editor)

void windowTitleChanged (EditorPartWindow *editor)


Public Member Functions

 VisualizationViewTransformable ()

virtual ~VisualizationViewTransformable ()

template<typename Reflector >
void reflect (Reflector &r)

void reflect (XMLDeserializer &r)
 Specialization of reflect method for XML. More...

void reflect (XMLSerializer &r)
 Specialization of reflect method for XML. More...

virtual void addVisualization (Visualization *vis)
 Adds an existing visualization to this view. More...

virtual void removeVisualization (Visualization *vis)
 Remove the specified visualization from this view. More...

virtual void moveUpVisualization (Visualization *vis)
 Change order of visualizations in the view, move the specified visualization up. More...

virtual void moveDownVisualization (Visualization *vis)
 Change order of visualizations in the view, move the specified visualization down. More...

const std::list< Visualization * > & getVisualizations () const

virtual void addTool (VisualizationTool *tool)
 Adds an existing tool to this view. More...

const std::vector< VisualizationTool * > & getTools () const

VisualizationControlPagegetControl ()
 Returns pointer to VisualizationControlPage (or NULL, if no such page was created yet. More...

virtual ObjectgetAdapter (const Class &adapter)
 Returns an object which is an instance of the given class associated with this object. More...

virtual const ClasssupportedVisualizationClass () const =0
 Derived visualization views must return the base class of their supported visualizations. More...

virtual const ClassdefaultVisualizationClass () const
 If a default visualization class is provided, this class is used to instantiate a default visualization for data objects, no other specialized visualization is found for. More...

virtual const ClasssupportedVisualizationToolClass () const
 Derived visualization views may return the base class of their supported tools. More...

void setUpdateInterval (int interval)

int getUpdateInterval ()

VisualizationToolgetActiveTool ()
 Returns the current active tool, or NULL of no tool is active. More...

void activateTool (VisualizationTool *tool)

void setOfferAuxiliaryVisualizations (bool on)

virtual void init (IWorkbenchPartSite *site)
 Is called by the workbench. More...

IWorkbenchPartSitegetSite ()

virtual QImage captureContent ()
 Returns the content of the editor part as QImage. More...

void setWidget (QWidget *widget)

QWidget * widget () const

EditorPartTitleBargetTitleBar ()

void undock ()
 Undocks the window from the EditorPartArea and makes it floating. More...

void dock ()
 Docks the window back to the EditorPartArea. More...

bool isDocked () const
 Returns true, if the window is docked in the EditorPartArea. More...

void setOnTop (bool onTop)
 Makes the window stay on top of other windows. More...

bool isOnTop () const
 Returns true, if the window stays on top of other windows. More...

void showDecorations (bool show)

void setAutoHideDecorations (bool on)

virtual void activate ()
 Is called by the Workbench to inform the Part that is being activated by the user. More...

virtual void deactivate ()
 Is called by the Workbench to inform the Part that is being deactivated since another Part got the focus. More...

bool isActivated () const
 Returns true if this ViewPart currently has the focus and hence the users attention. More...

Class const & getClass () const
 call the virtual internalGetClass(). More...


Static Public Member Functions

static PseudoClass const & CLASS ()


Protected Slots

void onMinimized ()

void onMaximized ()

void onRestored ()

void onUndock ()

void onDock ()

void onOnTop (bool onTop)


Protected Member Functions

virtual void setCameraFrame (const TransformProperty &frame)

virtual QWidget * createPartControl ()
 Must be overloaded in subclasses to create the actual widget for this EditorPart. More...

virtual QWidget * createVisualizationPart ()=0

virtual void resetView ()

virtual void saveContentToFile ()

virtual void update (Duration dt)=0
 Is called by this class within the update timer event to update the view. More...

void startUpdateTimer ()

virtual void timerEvent (QTimerEvent *)

bool eventFilter (QObject *obj, QEvent *event)

void keyPressEvent (QKeyEvent *event)

void keyReleaseEvent (QKeyEvent *event)

void focusOutEvent (QFocusEvent *event)

std::string getChannelIDFromMimeData (const QMimeData *mimeData)

std::list< ClassProxygetVisualizationsFor (const std::string &channelID)

void dragEnterEventImpl (QDragEnterEvent *event)

void dropEventImpl (QDropEvent *event, QWidget *widget)

void destroyVisualizations ()

void destroyTools ()

QMenu * getViewMenu ()
 Returns the optional editor menu that is shown when the user clicks the editor menu tool button. More...

virtual void closeEvent (QCloseEvent *)

virtual void paintEvent (QPaintEvent *paintEvent)

virtual void changeEvent (QEvent *event)

void setActive (bool activate)

virtual void windowStateChanged (Qt::WindowStates oldState, Qt::WindowStates newState)

void updateDecorations ()

void updateStateButtons ()

virtual Class const & internalGetClass () const =0


Protected Attributes

TransformProperty mFixedFrame

TransformProperty mCameraFrame


Detailed Description

Abstract base class for 2D, 3D, text and plot visualization views (namely Visualization2DView and Visualization3DView...) that support a target frame.

Constructor & Destructor Documentation

◆ VisualizationViewTransformable()

◆ ~VisualizationViewTransformable()

virtual ~VisualizationViewTransformable ( )
virtual

Member Function Documentation

◆ reflect() [1/3]

void reflect ( Reflector &  r)
inline

◆ setCameraFrame()

virtual void setCameraFrame ( const TransformProperty frame)
inlineprotectedvirtual

Reimplemented in Visualization3DView.

◆ reflect() [2/3]

void reflect ( XMLDeserializer r)
inherited

Specialization of reflect method for XML.

◆ reflect() [3/3]

void reflect ( XMLSerializer r)
inherited

Specialization of reflect method for XML.

◆ addVisualization()

virtual void addVisualization ( Visualization vis)
virtualinherited

Adds an existing visualization to this view.

The view will take ownership of the visualization and will destroy it upon its own deletion.

Reimplemented in Visualization3DView, and Visualization2DView.

◆ removeVisualization()

virtual void removeVisualization ( Visualization vis)
virtualinherited

Remove the specified visualization from this view.

The view will give up its ownership of the visualization and the Visualization must be destroyed outside of this view.

◆ moveUpVisualization()

virtual void moveUpVisualization ( Visualization vis)
virtualinherited

Change order of visualizations in the view, move the specified visualization up.

The base VisualizationView just changes the order in the stored list of visualizations. Subclasses should overwrite this method to adapt their respective GUI accordingly.

Reimplemented in Visualization3DView, and Visualization2DView.

◆ moveDownVisualization()

virtual void moveDownVisualization ( Visualization vis)
virtualinherited

Change order of visualizations in the view, move the specified visualization down.

The base VisualizationView just changes the order in the stored list of visualizations. Subclasses should overwrite this method to adapt their respective GUI accordingly.

Reimplemented in Visualization3DView, and Visualization2DView.

◆ getVisualizations()

const std::list<Visualization*>& getVisualizations ( ) const
inherited

◆ addTool()

virtual void addTool ( VisualizationTool tool)
virtualinherited

Adds an existing tool to this view.

The view will take ownership of the tool and will destroy it upon its own deletion.

Reimplemented in Visualization3DView, and Visualization2DView.

◆ getTools()

const std::vector<VisualizationTool*>& getTools ( ) const
inherited

◆ getControl()

VisualizationControlPage* getControl ( )
inherited

Returns pointer to VisualizationControlPage (or NULL, if no such page was created yet.

◆ getAdapter()

virtual Object* getAdapter ( const Class adapter)
virtualinherited

Returns an object which is an instance of the given class associated with this object.

Returns nullptr if no such object can be found. The implementation if IAdaptable is responsible for destroying the instance of the created object.

Reimplemented from WorkbenchPart.

◆ supportedVisualizationClass()

virtual const Class& supportedVisualizationClass ( ) const
pure virtualinherited

Derived visualization views must return the base class of their supported visualizations.

Implemented in Visualization3DView, and Visualization2DView.

◆ defaultVisualizationClass()

virtual const Class& defaultVisualizationClass ( ) const
inlinevirtualinherited

If a default visualization class is provided, this class is used to instantiate a default visualization for data objects, no other specialized visualization is found for.

If no default visualization class exists, such data objects can not be visualized (the default behavior).

◆ supportedVisualizationToolClass()

virtual const Class& supportedVisualizationToolClass ( ) const
inlinevirtualinherited

Derived visualization views may return the base class of their supported tools.

The default implementation returns a null-class to indicate that no tools are supported.

Reimplemented in Visualization3DView, and Visualization2DView.

◆ createPartControl()

virtual QWidget* createPartControl ( )
protectedvirtualinherited

Must be overloaded in subclasses to create the actual widget for this EditorPart.

This EditorPart should be set as parent for the created widget.

Implements EditorPart.

◆ createVisualizationPart()

virtual QWidget* createVisualizationPart ( )
protectedpure virtualinherited

◆ resetView()

virtual void resetView ( )
protectedvirtualinherited

Reimplemented in Visualization3DView, and Visualization2DView.

◆ saveContentToFile()

virtual void saveContentToFile ( )
protectedvirtualinherited

Reimplemented in Visualization3DView, and Visualization2DView.

◆ update()

virtual void update ( Duration  dt)
protectedpure virtualinherited

Is called by this class within the update timer event to update the view.

The visualizations of the view have been updated before this method is called. The update cycle must be enabled by calling startUpdateTimer() after the derived class and its GUI components have been enabled

Implemented in Visualization3DView, and Visualization2DView.

◆ setUpdateInterval()

void setUpdateInterval ( int  interval)
inherited

◆ getUpdateInterval()

int getUpdateInterval ( )
inherited

◆ getActiveTool()

VisualizationTool* getActiveTool ( )
inlineinherited

Returns the current active tool, or NULL of no tool is active.

◆ activateTool()

void activateTool ( VisualizationTool tool)
inherited

◆ setOfferAuxiliaryVisualizations()

void setOfferAuxiliaryVisualizations ( bool  on)
inlineinherited

◆ startUpdateTimer()

void startUpdateTimer ( )
protectedinherited

◆ timerEvent()

virtual void timerEvent ( QTimerEvent *  )
protectedvirtualinherited

◆ eventFilter()

bool eventFilter ( QObject *  obj,
QEvent *  event
)
protectedinherited

◆ keyPressEvent()

void keyPressEvent ( QKeyEvent *  event)
protectedinherited

◆ keyReleaseEvent()

void keyReleaseEvent ( QKeyEvent *  event)
protectedinherited

◆ focusOutEvent()

void focusOutEvent ( QFocusEvent *  event)
protectedinherited

◆ getChannelIDFromMimeData()

std::string getChannelIDFromMimeData ( const QMimeData *  mimeData)
protectedinherited

◆ getVisualizationsFor()

std::list<ClassProxy> getVisualizationsFor ( const std::string &  channelID)
protectedinherited

◆ dragEnterEventImpl()

void dragEnterEventImpl ( QDragEnterEvent *  event)
protectedinherited

◆ dropEventImpl()

void dropEventImpl ( QDropEvent *  event,
QWidget *  widget
)
protectedinherited

◆ destroyVisualizations()

void destroyVisualizations ( )
protectedinherited

◆ destroyTools()

void destroyTools ( )
protectedinherited

◆ init()

virtual void init ( IWorkbenchPartSite site)
virtualinherited

Is called by the workbench.

The WorkbenchPart should initialize itself and my store the pointer tothe IWorkbenchPartSite interface for later use.

Implements WorkbenchPart.

◆ getSite()

IWorkbenchPartSite* getSite ( )
inherited

◆ captureContent()

virtual QImage captureContent ( )
virtualinherited

Returns the content of the editor part as QImage.

Can be reimplemented by subclasses to provide special capturing techniques that are e.g. required by OpenQL widgets.

Reimplemented in Visualization3DView.

◆ getViewMenu()

QMenu* getViewMenu ( )
protectedinherited

Returns the optional editor menu that is shown when the user clicks the editor menu tool button.

An EditorPart can add items to this menu within it's createPartControl() method, by calling this method and populating items to the menu.

◆ closeEvent()

virtual void closeEvent ( QCloseEvent *  )
protectedvirtualinherited

◆ editorClosed

void editorClosed ( EditorPart editor)
signalinherited

◆ editorDestroyed

void editorDestroyed ( EditorPart editor)
signalinherited

◆ setWidget()

void setWidget ( QWidget *  widget)
inherited

◆ widget()

QWidget* widget ( ) const
inherited

◆ getTitleBar()

EditorPartTitleBar* getTitleBar ( )
inherited

◆ undock()

void undock ( )
inlineinherited

Undocks the window from the EditorPartArea and makes it floating.

◆ dock()

void dock ( )
inlineinherited

Docks the window back to the EditorPartArea.

◆ isDocked()

bool isDocked ( ) const
inlineinherited

Returns true, if the window is docked in the EditorPartArea.

◆ setOnTop()

void setOnTop ( bool  onTop)
inlineinherited

Makes the window stay on top of other windows.

◆ isOnTop()

bool isOnTop ( ) const
inlineinherited

Returns true, if the window stays on top of other windows.

◆ showDecorations()

void showDecorations ( bool  show)
inherited

◆ setAutoHideDecorations()

void setAutoHideDecorations ( bool  on)
inherited

◆ paintEvent()

virtual void paintEvent ( QPaintEvent *  paintEvent)
protectedvirtualinherited

◆ changeEvent()

virtual void changeEvent ( QEvent *  event)
protectedvirtualinherited

◆ setActive()

void setActive ( bool  activate)
protectedinherited

◆ windowStateChanged()

virtual void windowStateChanged ( Qt::WindowStates  oldState,
Qt::WindowStates  newState
)
protectedvirtualinherited

◆ updateDecorations()

void updateDecorations ( )
protectedinherited

◆ updateStateButtons()

void updateStateButtons ( )
protectedinherited

◆ onMinimized

void onMinimized ( )
protectedslotinherited

◆ onMaximized

void onMaximized ( )
protectedslotinherited

◆ onRestored

void onRestored ( )
protectedslotinherited

◆ onUndock

void onUndock ( )
protectedslotinherited

◆ onDock

void onDock ( )
protectedslotinherited

◆ onOnTop

void onOnTop ( bool  onTop)
protectedslotinherited

◆ windowTitleChanged

void windowTitleChanged ( EditorPartWindow editor)
signalinherited

◆ activate()

virtual void activate ( )
virtualinherited

Is called by the Workbench to inform the Part that is being activated by the user.

Implements IWorkbenchPart.

Reimplemented in ViewPart.

◆ deactivate()

virtual void deactivate ( )
virtualinherited

Is called by the Workbench to inform the Part that is being deactivated since another Part got the focus.

Implements IWorkbenchPart.

Reimplemented in ViewPart.

◆ isActivated()

bool isActivated ( ) const
inlineinherited

Returns true if this ViewPart currently has the focus and hence the users attention.

◆ getClass()

Class const& getClass ( ) const
inlineinherited

call the virtual internalGetClass().

◆ CLASS()

static PseudoClass const& CLASS ( )
inlinestaticinherited

◆ internalGetClass()

virtual Class const& internalGetClass ( ) const
protectedpure virtualinherited

Member Data Documentation

◆ mFixedFrame

TransformProperty mFixedFrame
protected

◆ mCameraFrame

TransformProperty mCameraFrame
protected

The documentation for this class was generated from the following file:
