#include <fw/FrameworkWithGui.h>

Inheritance diagram for FrameworkWithGui:

[legend]

Classes
class	Application
	Implements our own Application derived from QApplication in order to overwrite the notify method. More...

Public Types
typedef ProtecteeMixin< MetaTypeDatabase >	ProtecteeDatabase

typedef Base::Type	Type

Public Member Functions
	FrameworkWithGui (int &argc, char **argv, bool startImmediately=false)
	Constructor that creates own FrameworkWithGui::Application. More...

	FrameworkWithGui (int &argc, char *argv, QApplication app, bool startImmediately=false)
	Constructor that takes previously created QApplication. More...

	~FrameworkWithGui ()

virtual int	exec ()
	Executes the framework and executes the underlying QApplication until the application is terminated, e.g. More...

virtual void	requestTermination (int exitcode=0)
	Requests the termination of the framework and hence the whole application. More...

template<typename Reflector >
void	reflect (Reflector &r)
	Reflect method for serialization. More...

boost::shared_ptr< PropertyNode >	getProperties ()

void	load (XMLDom &xml)
	Loads the specified XML configuration and applies all registered Loaders on it. More...

void	load (const std::string &configFile)
	Opens the specified XML configuration file and applies all registered Loaders on it. More...

void	load ()
	Loads configuration files given on command line if any by calling above load(const std::string& configFile) function. More...

void	start ()
	Starts the framework and it's remote component (if one was configured or created) and returns immediately. More...

bool	isStarted () const
	Return true if framework is started. More...

Duration	getUptime () const
	Return duration since started. More...

virtual bool	isTerminationRequested () const
	Returns whether the termination of the framework is reqested. More...

int	getTerminationExitCode () const
	Returns the exit code as specified by requestTermination(), or 0 if requestTermination() was not called. More...

int	run ()
	Calls the above load() and start() methods according to the command line parameters that were passed in the constructor and finally calls exec(). More...

std::string	getID () const
	Returns the ID of this framework. More...

std::string	getGlobalID () const
	Return the fully qualified global id of this framework (includes namespace) More...

XMLVariablesMap &	getVariables ()
	Returns the list of variables that are registered via command line or config file. More...

XMLDomPreprocessor &	getXMLDomPreprocessor ()

ScopedAccess< ProtecteeDatabase >	getMetaDatabase ()
	Return the meta database that contains all known meta information in this framework. More...

bool	isInExec () const

Obtain access to framework components
NameRegistry &	getNameRegistry ()
	Returns the reference to the name registry. More...

AuthorityManager &	getAuthorityManager ()
	Returns the reference to the manager singleton for registered authorities. More...

ChannelManager &	getChannelManager ()
	Returns the reference to the manager singleton for channels. More...

boost::shared_ptr< FrameworkTransformer >	getTransformer ()
	Returns the pointer to the transform framework. More...

ConfigurationLoader &	getConfigurationLoader ()
	Returns the reference to the configuration file loader. More...

boost::shared_ptr< UnitManager >	getUnitManager ()
	Returns the reference to the unit manager. More...

RPCManager &	getRPCManager ()
	Returns the reference to the manager singleton for registered RPC services. More...

boost::shared_ptr< ErrorService >	getErrorService ()
	Returns the pointer to the persistent error service. More...

boost::shared_ptr< RemoteModule >	getRemoteModule ()
	Returns the pointer to the remote module. More...

Static Public Member Functions
static Type &	instance ()
	Returns a reference to the singleton instance. More...

static bool	isDestroyed ()
	Returns true, if the singleton was already destroyed. More...

Protected Member Functions
void	initialize ()

void	finalize ()

void	ctrlCHandler (const IntSignal &sig)

Static Protected Member Functions
static void	errorHandler (const IntSignal &sig)

static bool	enterLeaveErrorHandler (bool enter)

Protected Attributes
bool	mTerminationRequested

int	mTerminationExitCode

bool	mIsStarted

bool	mInExec

bool	mRemoteDisabled

boost::shared_ptr< Private::FrameworkAuthority >	mAuthority

RootPropertyNode	mPropertiesRoot

boost::shared_ptr< PropertyNode >	mProperties

NameRegistry	mNames

boost::shared_ptr< RemoteModule >	mRemoteModule

RPCManager	mRPCManager

ChannelManager	mChannelManager

AuthorityManager	mAuthorityManager

boost::shared_ptr< FrameworkTransformer >	mTransformer

boost::shared_ptr< UnitManager >	mUnitManager

ConfigurationLoader	mConfigurationLoader

boost::shared_ptr< ErrorService >	mErrorServiceModule

std::string	mName

XMLDomPreprocessor	mXMLPreprocessor

XMLDom	mConfigDom

ProtecteeDatabase	mMetaDatabase

Time	mStartTime

Member Typedef Documentation

◆ ProtecteeDatabase

typedef ProtecteeMixin<MetaTypeDatabase> ProtecteeDatabase

inherited

◆ Type

typedef Base::Type Type

inherited

Constructor & Destructor Documentation

◆ FrameworkWithGui() [1/2]

FrameworkWithGui	(	int &	argc,
		char **	argv,
		bool	startImmediately = `false`
	)

inline

Constructor that creates own FrameworkWithGui::Application.

◆ FrameworkWithGui() [2/2]

FrameworkWithGui	(	int &	argc,
		char **	argv,
		QApplication *	app,
		bool	startImmediately = `false`
	)

inline

Constructor that takes previously created QApplication.

The caller is responsible for destroying the application at the end.

◆ ~FrameworkWithGui()

~FrameworkWithGui ( )

inline

Member Function Documentation

◆ exec()

virtual int exec ( )

inlinevirtual

Executes the framework and executes the underlying QApplication until the application is terminated, e.g.

by closing it or by pressing Ctrl+C.

Reimplemented from Framework.

◆ requestTermination()

virtual void requestTermination ( int exitcode = 0 )

inlinevirtual

Requests the termination of the framework and hence the whole application.

Is called e.g. when user presses Ctrl+C. You can optionally specify an exit code that will be returned as exit code by exec(). Furthermore, this code is returned by the mira executables (mira, miragui, miracenter, etc.).

Reimplemented from Framework.

◆ reflect()

void reflect ( Reflector & r )

inlineinherited

Reflect method for serialization.

◆ getProperties()

boost::shared_ptr<PropertyNode> getProperties ( )

inlineinherited

◆ load() [1/3]

void load ( XMLDom & xml )

inherited

Loads the specified XML configuration and applies all registered Loaders on it.

This will load libraries, instantiate and configure units, etc. This method will do nothing if the xml document is empty.

◆ load() [2/3]

void load ( const std::string & configFile )

inherited

Opens the specified XML configuration file and applies all registered Loaders on it.

This will load libraries, instantiate and configure units, etc. This method will do nothing if configFile is empty.

◆ load() [3/3]

void load ( )

inherited

Loads configuration files given on command line if any by calling above load(const std::string& configFile) function.

◆ start()

void start ( )

inherited

Starts the framework and it's remote component (if one was configured or created) and returns immediately.

◆ isStarted()

bool isStarted ( ) const

inlineinherited

Return true if framework is started.

◆ getUptime()

Duration getUptime ( ) const

inlineinherited

Return duration since started.

◆ isTerminationRequested()

virtual bool isTerminationRequested ( ) const

virtualinherited

Returns whether the termination of the framework is reqested.

◆ getTerminationExitCode()

int getTerminationExitCode ( ) const

inherited

Returns the exit code as specified by requestTermination(), or 0 if requestTermination() was not called.

See also: isTerminationRequested().

◆ run()

int run ( )

inherited

Calls the above load() and start() methods according to the command line parameters that were passed in the constructor and finally calls exec().

Hence, this method will launch a fully operating framework and blocks until the framework is terminated, e.g. by pressing Ctrl+C. Returns the exit code as specified by requestTermination(), or 0 if no error or exception has occurred, otherwise -1.

◆ getNameRegistry()

NameRegistry& getNameRegistry ( )

inlineinherited

Returns the reference to the name registry.

◆ getAuthorityManager()

AuthorityManager& getAuthorityManager ( )

inlineinherited

Returns the reference to the manager singleton for registered authorities.

◆ getChannelManager()

ChannelManager& getChannelManager ( )

inlineinherited

Returns the reference to the manager singleton for channels.

◆ getTransformer()

boost::shared_ptr<FrameworkTransformer> getTransformer ( )

inlineinherited

Returns the pointer to the transform framework.

◆ getConfigurationLoader()

ConfigurationLoader& getConfigurationLoader ( )

inlineinherited

Returns the reference to the configuration file loader.

◆ getUnitManager()

boost::shared_ptr<UnitManager> getUnitManager ( )

inlineinherited

Returns the reference to the unit manager.

◆ getRPCManager()

RPCManager& getRPCManager ( )

inlineinherited

Returns the reference to the manager singleton for registered RPC services.

◆ getErrorService()

boost::shared_ptr<ErrorService> getErrorService ( )

inlineinherited

Returns the pointer to the persistent error service.

◆ getRemoteModule()

boost::shared_ptr<RemoteModule> getRemoteModule ( )

inlineinherited

Returns the pointer to the remote module.

◆ getID()

std::string getID ( ) const

inlineinherited

Returns the ID of this framework.

The ID can be specified via command line. If no ID is specified an UUID based one will be generated.

◆ getGlobalID()

std::string getGlobalID ( ) const

inlineinherited

Return the fully qualified global id of this framework (includes namespace)

Returns: Global ID

◆ getVariables()

XMLVariablesMap& getVariables ( )

inlineinherited

Returns the list of variables that are registered via command line or config file.

◆ getXMLDomPreprocessor()

XMLDomPreprocessor& getXMLDomPreprocessor ( )

inlineinherited

◆ getMetaDatabase()

ScopedAccess<ProtecteeDatabase> getMetaDatabase ( )

inlineinherited

Return the meta database that contains all known meta information in this framework.

◆ isInExec()

bool isInExec ( ) const

inlineinherited

◆ initialize()

void initialize ( )

protectedinherited

◆ finalize()

void finalize ( )

protectedinherited

◆ ctrlCHandler()

void ctrlCHandler ( const IntSignal & sig )

protectedinherited

◆ errorHandler()

static void errorHandler ( const IntSignal & sig )

staticprotectedinherited

◆ enterLeaveErrorHandler()

static bool enterLeaveErrorHandler ( bool enter )

staticprotectedinherited

◆ instance()

static Type& instance ( )

inlinestaticinherited

Returns a reference to the singleton instance.

Exceptions

XLogical If the singleton was already destroyed (dead reference) or not yet created (when using ExplicitInstantiation).

◆ isDestroyed()

static bool isDestroyed ( )

inlinestaticinherited

Returns true, if the singleton was already destroyed.

Trying to access it will result in an exception.

Member Data Documentation

◆ mTerminationRequested

bool mTerminationRequested

protectedinherited

◆ mTerminationExitCode

int mTerminationExitCode

protectedinherited

◆ mIsStarted

bool mIsStarted

protectedinherited

◆ mInExec

bool mInExec

protectedinherited

◆ mRemoteDisabled

bool mRemoteDisabled

protectedinherited

◆ mAuthority

boost::shared_ptr<Private::FrameworkAuthority> mAuthority

protectedinherited

◆ mPropertiesRoot

RootPropertyNode mPropertiesRoot

protectedinherited

◆ mProperties

boost::shared_ptr<PropertyNode> mProperties

protectedinherited

◆ mNames

NameRegistry mNames

protectedinherited

◆ mRemoteModule

boost::shared_ptr<RemoteModule> mRemoteModule

protectedinherited

◆ mRPCManager

RPCManager mRPCManager

protectedinherited

◆ mChannelManager

ChannelManager mChannelManager

protectedinherited

◆ mAuthorityManager

AuthorityManager mAuthorityManager

protectedinherited

◆ mTransformer

boost::shared_ptr<FrameworkTransformer> mTransformer

protectedinherited

◆ mUnitManager

boost::shared_ptr<UnitManager> mUnitManager

protectedinherited

◆ mConfigurationLoader

ConfigurationLoader mConfigurationLoader

protectedinherited

◆ mErrorServiceModule

boost::shared_ptr<ErrorService> mErrorServiceModule

protectedinherited

◆ mName

std::string mName

protectedinherited

◆ mXMLPreprocessor

XMLDomPreprocessor mXMLPreprocessor

protectedinherited

◆ mConfigDom

XMLDom mConfigDom

protectedinherited

◆ mMetaDatabase

ProtecteeDatabase mMetaDatabase

protectedinherited

◆ mStartTime

Time mStartTime

protectedinherited

The documentation for this class was generated from the following file:

gui/include/fw/FrameworkWithGui.h

Classes

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Static Protected Member Functions

Protected Attributes

Member Typedef Documentation

◆ ProtecteeDatabase

◆ Type

Constructor & Destructor Documentation

◆ FrameworkWithGui() [1/2]

◆ FrameworkWithGui() [2/2]

◆ ~FrameworkWithGui()

Member Function Documentation

◆ exec()

◆ requestTermination()

◆ reflect()

◆ getProperties()

◆ load() [1/3]

◆ load() [2/3]

◆ load() [3/3]

◆ start()

◆ isStarted()

◆ getUptime()

◆ isTerminationRequested()

◆ getTerminationExitCode()

◆ run()

◆ getNameRegistry()

◆ getAuthorityManager()

◆ getChannelManager()

◆ getTransformer()

◆ getConfigurationLoader()

◆ getUnitManager()

◆ getRPCManager()

◆ getErrorService()

◆ getRemoteModule()

◆ getID()

◆ getGlobalID()

◆ getVariables()

◆ getXMLDomPreprocessor()

◆ getMetaDatabase()

◆ isInExec()

◆ initialize()

◆ finalize()

◆ ctrlCHandler()

◆ errorHandler()

◆ enterLeaveErrorHandler()

◆ instance()

◆ isDestroyed()

Member Data Documentation

◆ mTerminationRequested

◆ mTerminationExitCode

◆ mIsStarted

◆ mInExec

◆ mRemoteDisabled

◆ mAuthority

◆ mPropertiesRoot

◆ mProperties

◆ mNames

◆ mRemoteModule

◆ mRPCManager

◆ mChannelManager

◆ mAuthorityManager

◆ mTransformer

◆ mUnitManager

◆ mConfigurationLoader

◆ mErrorServiceModule

◆ mName

◆ mXMLPreprocessor

◆ mConfigDom

◆ mMetaDatabase

◆ mStartTime
